Icom IC-703 Service Manual page 46

[MAIN UNIT]
REF ORDER
NO. NO.
R2742 7030003560 S.RESISTOR
R2743 7030003680 S.RESISTOR
R2744 7030003800 S.RESISTOR
R2745 7030003400 S.RESISTOR
R2761 7030003400 S.RESISTOR
R2762 7030003840 S.RESISTOR
R2764 7030003620 S.RESISTOR
R2765 7310002740 S.TRIMMER
R2766 7030003620 S.RESISTOR
R2767 7030003640 S.RESISTOR
R2768 7030003640 S.RESISTOR
R2781 7030003840 S.RESISTOR
R2783 7030003560 S.RESISTOR
R2786 7030003440 S.RESISTOR
R2787 7030003560 S.RESISTOR
R2788 7030003680 S.RESISTOR
R2789 7030003400 S.RESISTOR
R4001 7030003580 S.RESISTOR
R4002 7030003550 S.RESISTOR
R4003 7030003640 S.RESISTOR
R4004 7030003570 S.RESISTOR
R4005 7030003680 S.RESISTOR
R4006 7030003680 S.RESISTOR
R5101 7030003440 S.RESISTOR
R5102 7030003640 S.RESISTOR
R5103 7030003440 S.RESISTOR
R5104 7030003640 S.RESISTOR
R5105 7030003440 S.RESISTOR
R5106 7030003640 S.RESISTOR
R5201 7030003440 S.RESISTOR
R5202 7030003640 S.RESISTOR
R5203 7030003440 S.RESISTOR
R5204 7030003640 S.RESISTOR
R5301 7030003440 S.RESISTOR
R5303 7030003440 S.RESISTOR
R5304 7030003640 S.RESISTOR
R5305 7030003440 S.RESISTOR
R5306 7030003640 S.RESISTOR
R5307 7030003440 S.RESISTOR
R5308 7030003640 S.RESISTOR
R5401 7030003770 S.RESISTOR
R5402 7030003790 S.RESISTOR
R5403 7030003640 S.RESISTOR
R5405 7030003640 S.RESISTOR
R5406 7030003670 S.RESISTOR
R5501 7030003440 S.RESISTOR
R5502 7030003440 S.RESISTOR
R5503 7030003440 S.RESISTOR
R5504 7030003440 S.RESISTOR
R5505 7030003440 S.RESISTOR
R5506 7030006101 S.RESISTOR
R5507 7030006571 S.RESISTOR
R5508 7030003320 S.RESISTOR
R5509 7030003600 S.RESISTOR
R5510 7030003640 S.RESISTOR
R5511 7030003600 S.RESISTOR
R5512 7030003600 S.RESISTOR
R5513 7030003410 S.RESISTOR
R5514 7030003640 S.RESISTOR
R5600 7030003560 S.RESISTOR
R5601 7030003440 S.RESISTOR
R5602 7030003440 S.RESISTOR
R5603 7030003440 S.RESISTOR
R5604 7030003440 S.RESISTOR
R5605 7030003640 S.RESISTOR
R5606 7030003680 S.RESISTOR
R5607 7030003680 S.RESISTOR
R5608 7030003800 S.RESISTOR
R5701 7030003440 S.RESISTOR
R5702 7030003800 S.RESISTOR
R5703 7030003640 S.RESISTOR
R5704 7030003670 S.RESISTOR
R5705 7030003440 S.RESISTOR
R5706 7030003640 S.RESISTOR
R5711 7030003440 S.RESISTOR
R5712 7030003640 S.RESISTOR
R5804 7030003440 S.RESISTOR
R5805 7030003440 S.RESISTOR
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 333 V (33 kΩ)
RV-150 (RH03A3A14X0FC) 103
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 225 V (2.2 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 824 V (820 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERA3YED 183V
ERA3YED 392V
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 561 V (560 Ω)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
[MAIN UNIT]
REF ORDER
NO. NO.
R5806 7030003440 S.RESISTOR
R5807 7030003440 S.RESISTOR
R5812 7030003440 S.RESISTOR
R5814 7030003440 S.RESISTOR
R5815 7030003440 S.RESISTOR
R5816 7030003440 S.RESISTOR
R5851 7030003440 S.RESISTOR
R5852 7030003640 S.RESISTOR
R5899 7030003640 S.RESISTOR
R5901 7030003680 S.RESISTOR
R5903 7030003560 S.RESISTOR
R5921 7030003600 S.RESISTOR
R5922 7030003560 S.RESISTOR
R5923 7030003680 S.RESISTOR
R5924 7030003720 S.RESISTOR
R5925 7030003680 S.RESISTOR
R5926 7030003680 S.RESISTOR
R5927 7030003720 S.RESISTOR
R5928 7030003540 S.RESISTOR
R5929 7030003560 S.RESISTOR
R5961 7030003600 S.RESISTOR
R5962 7030003560 S.RESISTOR
R5981 7030007911 S.RESISTOR
R5982 7030005981 S.RESISTOR
R6001 7030003440 S.RESISTOR
R6002 7030003640 S.RESISTOR
R6003 7030003440 S.RESISTOR
R6004 7030003440 S.RESISTOR
R6005 7030003560 S.RESISTOR
R6006 7030003440 S.RESISTOR
R6007 7030003440 S.RESISTOR
R6008 7030003400 S.RESISTOR
R6009 7030003400 S.RESISTOR
R6010 7030003440 S.RESISTOR
R6012 7030003440 S.RESISTOR
R6013 7030003440 S.RESISTOR
R6101 7030003640 S.RESISTOR
R6102 7030003440 S.RESISTOR
R6103 7030003440 S.RESISTOR
R6104 7030003440 S.RESISTOR
R6105 7030003440 S.RESISTOR
R6151 7030003440 S.RESISTOR
R6201 7030003520 S.RESISTOR
R6202 7030003520 S.RESISTOR
R6301 7030003440 S.RESISTOR
R6302 7030003440 S.RESISTOR
R6303 7030003440 S.RESISTOR
R6304 7030003440 S.RESISTOR
R6305 7030003440 S.RESISTOR
R6306 7030003440 S.RESISTOR
R6307 7030003440 S.RESISTOR
R6321 7030003600 S.RESISTOR
R6322 7030003440 S.RESISTOR
R6323 7030003640 S.RESISTOR
R6324 7030003440 S.RESISTOR
R6325 7030003640 S.RESISTOR
R6341 7030003600 S.RESISTOR
R6342 7030003440 S.RESISTOR
R6343 7030003640 S.RESISTOR
R6344 7030003440 S.RESISTOR
R6345 7030003560 S.RESISTOR
R6361 7030003560 S.RESISTOR
R6362 7030003440 S.RESISTOR
R6403 7030003440 S.RESISTOR
R6404 7030003440 S.RESISTOR
R6405 7030003440 S.RESISTOR
R6471 7030003640 S.RESISTOR
R6472 7030003620 S.RESISTOR
R6473 7030003580 S.RESISTOR
R6474 7030003520 S.RESISTOR
R6491 7030003440 S.RESISTOR
R6511 7030003560 S.RESISTOR
R6601 7030003640 S.RESISTOR
R6602 7030003620 S.RESISTOR
R6603 7030003580 S.RESISTOR
R6604 7030003520 S.RESISTOR
R6641 7030003440 S.RESISTOR
R6642 7030003680 S.RESISTOR
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 15
DESCRIPTION
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERA3YKD 563V (56 kΩ)
ERA3YED 333V
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
S.=Surface mount
