Icom IC-703 Service Manual page 36

[PA UNIT]
REF ORDER
NO. NO.
R508 7030000210 S.RESISTOR
R509 7030000210 S.RESISTOR
R520 7030003440 S.RESISTOR
R521 7030003440 S.RESISTOR
R522 7030003640 S.RESISTOR
R523 7030003640 S.RESISTOR
R524 7030003440 S.RESISTOR
R525 7030003440 S.RESISTOR
R526 7030003640 S.RESISTOR
R527 7030003640 S.RESISTOR
R528 7030000210 S.RESISTOR
R529 7030000210 S.RESISTOR
R561 7030003320 S.RESISTOR
R562 7030003520 S.RESISTOR
R563 7030003490 S.RESISTOR
R564 7030003560 S.RESISTOR
R565 7030003280 S.RESISTOR
R566 7030003320 S.RESISTOR
R567 7030003520 S.RESISTOR
R568 7030003490 S.RESISTOR
R569 7030003560 S.RESISTOR
R571 7030003320 S.RESISTOR
R572 7030003620 S.RESISTOR
R573 7030003620 S.RESISTOR
R574 7030003660 S.RESISTOR
R575 7030003620 S.RESISTOR
R600 7030003340 S.RESISTOR
R601 7030003560 S.RESISTOR
R603 7030003560 S.RESISTOR
R605 7030003560 S.RESISTOR
R606 7030003440 S.RESISTOR
R607 7030003440 S.RESISTOR
R608 7030003640 S.RESISTOR
R609 7030003440 S.RESISTOR
R610 7030003440 S.RESISTOR
R611 7030003440 S.RESISTOR
R612 7030003440 S.RESISTOR
R613 7030003560 S.RESISTOR
R614 7030003800 S.RESISTOR
R617 7030003440 S.RESISTOR
R618 7030003640 S.RESISTOR
R619 7030003640 S.RESISTOR
R620 7030003640 S.RESISTOR
R641 7030003480 S.RESISTOR
R642 7030003560 S.RESISTOR
R643 7030003200 S.RESISTOR
R645 7030003560 S.RESISTOR
R648 7030003560 S.RESISTOR
R649 7030003480 S.RESISTOR
R650 7030010520 S.RESISTOR
R651 7030010520 S.RESISTOR
R652 7030010520 S.RESISTOR
R653 7030010520 S.RESISTOR
R655 7030010820 S.RESISTOR
R657 7030010820 S.RESISTOR
R658 7030010820 S.RESISTOR
R659 7030006070 S.RESISTOR
R660 7030003770 S.RESISTOR
R661 7030003640 S.RESISTOR
R662 7030010940 S.RESISTOR
R663 7030010940 S.RESISTOR
R664 7030010940 S.RESISTOR
R665 7030010940 S.RESISTOR
R666 7030003480 S.RESISTOR
R667 7030003640 S.RESISTOR
R668 7030003480 S.RESISTOR
R669 7030003440 S.RESISTOR
R670 7030003730 S.RESISTOR
R671 7030003770 S.RESISTOR
R672 7030003340 S.RESISTOR
R673 7030003280 S.RESISTOR
R674 7540000260 ABSORBER
R675 7030003640 S.RESISTOR
R676 7030000250 S.RESISTOR
R677 7030000260 S.RESISTOR
R678 7030003560 S.RESISTOR
R679 7030003730 S.RESISTOR
R680 7030003560 S.RESISTOR
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 39 Ω (390)
A only
MCR10EZHJ 39 Ω (390)
A only
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ1TYJ 101U (100 Ω)
ERJ1TYJ 101U (100 Ω)
ERJ1TYJ 101U (100 Ω)
ERJ1TYJ 101U (100 Ω)
ERJ1TYJ 221U (220 Ω)
ERJ1TYJ 221U (220 Ω)
ERJ1TYJ 221U (220 Ω)
ERJ12YJ101U (100 Ω)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ12NF56R0U (56 Ω)
ERJ12NF56R0U (56 Ω)
ERJ12NF56R0U (56 Ω)
ERJ12NF56R0U (56 Ω)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 151 V (150 Ω)
ERJ3GEYJ 470 V (47 Ω)
SA05C 201M
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 82 Ω (820)
MCR10EZHJ 100 Ω (101)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
[PA UNIT]
REF ORDER
NO. NO.
R681 7030003730 S.RESISTOR
R682 7030003610 S.RESISTOR
R683 7030003280 S.RESISTOR
R684 7030003770 S.RESISTOR
R685 7030003440 S.RESISTOR
R686 7030003640 S.RESISTOR
R687 7030003440 S.RESISTOR
R688 7030003590 S.RESISTOR
R689 7030003440 S.RESISTOR
R690 7030000200 S.RESISTOR
R691 7030000180 S.RESISTOR
R693 7030003440 S.RESISTOR
R694 7030003440 S.RESISTOR
R695 7030003640 S.RESISTOR
R696 7030003680 S.RESISTOR
R700 7030003440 S.RESISTOR
R701 7030003640 S.RESISTOR
R702 7030003640 S.RESISTOR
R703 7030003440 S.RESISTOR
R704 7030003440 S.RESISTOR
R705 7030003640 S.RESISTOR
R706 7030003640 S.RESISTOR
R707 7030003440 S.RESISTOR
R708 7030003440 S.RESISTOR
R709 7030003640 S.RESISTOR
R710 7030003640 S.RESISTOR
R711 7030003440 S.RESISTOR
R712 7030003440 S.RESISTOR
R713 7030003640 S.RESISTOR
R714 7030003640 S.RESISTOR
R715 7030003440 S.RESISTOR
R716 7030003440 S.RESISTOR
R717 7030003640 S.RESISTOR
R718 7030003640 S.RESISTOR
R719 7030003440 S.RESISTOR
R720 7030003440 S.RESISTOR
R721 7030003640 S.RESISTOR
R722 7030003640 S.RESISTOR
R723 7030003440 S.RESISTOR
R724 7030003440 S.RESISTOR
R725 7030003640 S.RESISTOR
R726 7030003640 S.RESISTOR
R727 7030003440 S.RESISTOR
R728 7030003440 S.RESISTOR
R729 7030003640 S.RESISTOR
R730 7030003640 S.RESISTOR
R731 7030003440 S.RESISTOR
R732 7030003440 S.RESISTOR
R733 7030003640 S.RESISTOR
R734 7030003640 S.RESISTOR
R735 7030003440 S.RESISTOR
R736 7030003440 S.RESISTOR
R737 7030003640 S.RESISTOR
R738 7030003640 S.RESISTOR
R739 7030003440 S.RESISTOR
R750 7030000210 S.RESISTOR
R751 7030000210 S.RESISTOR
R752 7030000210 S.RESISTOR
R753 7030000210 S.RESISTOR
R754 7030000210 S.RESISTOR
R755 7030000210 S.RESISTOR
R756 7030000210 S.RESISTOR
R757 7030000210 S.RESISTOR
R758 7030000210 S.RESISTOR
R759 7030000210 S.RESISTOR
R800 7030003440 S.RESISTOR
R801 7030003640 S.RESISTOR
R802 7030003640 S.RESISTOR
R803 7030003440 S.RESISTOR
R804 7030003440 S.RESISTOR
R805 7030003640 S.RESISTOR
R806 7030003640 S.RESISTOR
R807 7030003440 S.RESISTOR
R808 7030003440 S.RESISTOR
R809 7030003640 S.RESISTOR
R810 7030003640 S.RESISTOR
R811 7030003440 S.RESISTOR
R812 7030003440 S.RESISTOR
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 5
DESCRIPTION
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 33 Ω (330)
MCR10EZHJ 22 Ω (220)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
S.=Surface mount
