Icom IC-703 Service Manual page 37

[PA UNIT]
REF ORDER
NO. NO.
R813 7030003640 S.RESISTOR
R814 7030003640 S.RESISTOR
R815 7030003440 S.RESISTOR
R816 7030003440 S.RESISTOR
R817 7030003640 S.RESISTOR
R818 7030003640 S.RESISTOR
R819 7030003440 S.RESISTOR
R820 7030003440 S.RESISTOR
R821 7030003640 S.RESISTOR
R822 7030003640 S.RESISTOR
R823 7030003440 S.RESISTOR
R824 7030003440 S.RESISTOR
R825 7030003640 S.RESISTOR
R826 7030003640 S.RESISTOR
R827 7030003440 S.RESISTOR
R828 7030003440 S.RESISTOR
R829 7030003640 S.RESISTOR
R830 7030003640 S.RESISTOR
R831 7030003440 S.RESISTOR
R832 7030003440 S.RESISTOR
R833 7030003640 S.RESISTOR
R834 7030003640 S.RESISTOR
R835 7030003440 S.RESISTOR
R836 7030003440 S.RESISTOR
R837 7030003640 S.RESISTOR
R838 7030003640 S.RESISTOR
R839 7030003440 S.RESISTOR
R840 7030003440 S.RESISTOR
R841 7030003640 S.RESISTOR
R842 7030003640 S.RESISTOR
R843 7030003440 S.RESISTOR
R850 7030000210 S.RESISTOR
R851 7030000210 S.RESISTOR
R852 7030000210 S.RESISTOR
R853 7030000210 S.RESISTOR
R854 7030000210 S.RESISTOR
R855 7030000210 S.RESISTOR
R856 7030000210 S.RESISTOR
R857 7030000210 S.RESISTOR
R858 7030000210 S.RESISTOR
R859 7030000210 S.RESISTOR
R860 7030000210 S.RESISTOR
R900 7030003680 S.RESISTOR
R901 7030003670 S.RESISTOR
R902 7030003440 S.RESISTOR
R903 7030003640 S.RESISTOR
C1 4030011600 S.CERAMIC
C2 4030011600 S.CERAMIC
C3 4030011600 S.CERAMIC
C4 4030006860 S.CERAMIC
C5 4030006860 S.CERAMIC
C6 4030006860 S.CERAMIC
C7 4030006860 S.CERAMIC
C8 4030006860 S.CERAMIC
C9 4550002810 S.TANTALUM
C10 4030011600 S.CERAMIC
C11 4030006880 S.CERAMIC
C12 4030006880 S.CERAMIC
C13 4030006880 S.CERAMIC
C14 4030011600 S.CERAMIC
C15 4510005500 ELECTROLYTIC 16 MV 10 HC
C47 4030006860 S.CERAMIC
C48 4030006860 S.CERAMIC
C49 4030006860 S.CERAMIC
C50 4030006860 S.CERAMIC
C51 4030006860 S.CERAMIC
C52 4030007090 S.CERAMIC
C53 4030007090 S.CERAMIC
C54 4030006860 S.CERAMIC
C55 4030006860 S.CERAMIC
C56 4030006860 S.CERAMIC
C57 4030006860 S.CERAMIC
C58 4030006860 S.CERAMIC
C59 4030006860 S.CERAMIC
C60 4030006860 S.CERAMIC
C80 4030007090 S.CERAMIC
A: [EUR], [EUR-1], [USA], [USA-1], [KOR], [KOR-1]
C: [FRA], [FRA-1], [ITA], [ITA-1]
E: [FRA], [FRA-1], [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
DESCRIPTION
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
MCR10EZHJ 39 Ω (390)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
TESVD2 1E 106M-12L
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
[PA UNIT]
REF ORDER
NO. NO.
C81 4030006850 S.CERAMIC
C82 4030006880 S.CERAMIC
C83 4030011600 S.CERAMIC
C84 4510004590 ELECTROLYTIC 16 MV 470 HC
C85 4030011600 S.CERAMIC
C86 4030006880 S.CERAMIC
C87 4030006880 S.CERAMIC
C88 4030006880 S.CERAMIC
C89 4510004590 ELECTROLYTIC 16 MV 470 HC
C100 4030007080 S.CERAMIC
C101 4030007010 S.CERAMIC
C102 4030007080 S.CERAMIC
C103 4030011600 S.CERAMIC
C104 4030011600 S.CERAMIC
C105 4030011600 S.CERAMIC
C106 4030011600 S.CERAMIC
C108 4030011600 S.CERAMIC
C109 4510004590 ELECTROLYTIC 16 MV 470 HC
C150 4030008960 S.CERAMIC
C151 4030011600 S.CERAMIC
C152 4030011600 S.CERAMIC
C153 4030011600 S.CERAMIC
C154 4030008960 S.CERAMIC
C155 4030008960 S.CERAMIC
C156 4030011600 S.CERAMIC
C157 4030008960 S.CERAMIC
C159 4030011600 S.CERAMIC
C160 4030011600 S.CERAMIC
C161 4030008960 S.CERAMIC
C162 4030006860 S.CERAMIC
C164 4030011600 S.CERAMIC
C165 4030008960 S.CERAMIC
C200 4030008960 S.CERAMIC
C201 4030008960 S.CERAMIC
C202 4030004740 S.CERAMIC
C203 4030004740 S.CERAMIC
C205 4030011230 S.CERAMIC
C207 4030011600 S.CERAMIC
C209 4030004740 S.CERAMIC
C210 4510004510 ELECTROLYTIC 25 MV 470 HC
C212 4030011510 S.CERAMIC
C213 4030011230 S.CERAMIC
C250 4030011600 S.CERAMIC
C251 4030006880 S.CERAMIC
C300 4030011600 S.CERAMIC
C301 4030011600 S.CERAMIC
C302 4030011600 S.CERAMIC
C303 4030011600 S.CERAMIC
C304 4030007050 S.CERAMIC
C305 4030007110 S.CERAMIC
C306 4030011540 S.CERAMIC
C307 4030007050 S.CERAMIC
C308 4030007080 S.CERAMIC
C309 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C400 4030006880 S.CERAMIC
C401 4030006880 S.CERAMIC
C402 4030017810 S.CERAMIC
C403 4030011340 S.CERAMIC
C404 4030017810 S.CERAMIC
C405 4030017810 S.CERAMIC
C406 4030011330 S.CERAMIC
C407 4030007160 S.CERAMIC
C408 4030017810 S.CERAMIC
C409 4030011340 S.CERAMIC
C410 4030006880 S.CERAMIC
C411 4030006880 S.CERAMIC
C412 4030006880 S.CERAMIC
C413 4030006880 S.CERAMIC
C414 4030006880 S.CERAMIC
C415 4030006880 S.CERAMIC
C420 4030006880 S.CERAMIC
C421 4030006880 S.CERAMIC
C422 4030017800 S.CERAMIC
C423 4030007160 S.CERAMIC
C424 4030017810 S.CERAMIC
C425 4030007120 S.CERAMIC
C426 4030017800 S.CERAMIC
C427 4030006880 S.CERAMIC
B: [EUR], [EUR-1], [ESP], [ESP-1], [OTH], [OTH-1]
D: [ESP], [ESP-1], [KOR], [KOR-1], [ITA], [ITA-1]
F: [FRA], [FRA-1], [ESP], [ESP-1], [OTH], OTH-1], [ITA], [ITA-1]
5 - 6
DESCRIPTION
C1608 JB 1H 471K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 390J-T
C1608 CH 1H 100D-T
C1608 CH 1H 390J-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C2012 JB 1C 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C1608 JB 1E 104K-T
C2012 JB 1C 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C2012 JB 1C 104K-T
C1608 JB 1H 102K-T
C1608 JB 1E 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1C 104K-T
C2012 JB 1H 472K-T
C2012 JB 1H 472K-T
GRM31M2C2H390JV01L
C1608 JB 1E 104K-T
C2012 JB 1H 472K-T
GRM31M2C2H560JV01L
GRM31M2C2H390JV01L
C1608 JB 1E 104K-T
C1608 JB 1H 472K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 CH 1H 220J-T
C1608 CH 1H 680J-T
C1608 CH 1H 750J-T
C1608 CH 1H 220J-T
C1608 CH 1H 390J-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 102J-T
C1608 CH 1H 471J-T
C1608 CH 1H 102J-T
C1608 CH 1H 102J-T
C1608 CH 1H 391J-T
C1608 CH 1H 181J-T
C1608 CH 1H 102J-T
C1608 CH 1H 471J-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 JB 1H 472K-T
C1608 CH 1H 561J-T
C1608 CH 1H 181J-T
C1608 CH 1H 102J-T
C1608 CH 1H 820J-T
C1608 CH 1H 561J-T
C1608 JB 1H 472K-T
S.=Surface mount
