8
4. Remove the bottom lamp assembly by pulling it out of the scanner,
and set it aside.
5. Push down on the right side of the glass flat and slide it to the right
until the glass flat slightly lifts away from the metal tray.
6. Holding the left side, gently pull the glass flat towards the left, taking
care not to twist or leverage the tip where it still touches the scanner.
and remove it from the scanner..
7. Insert the foam end of a Tech Wipe, flat side down, on top of the
bottom camera glass and gently wipe any dust particles from its
surface, making sure to cover the entire length of the glass.
8. When finished cleaning, re-insert the glass flat and the bottom lamp
assembly.
9. Close the side access panel.
10. Close the scanner transport cover.
11. Turn on the scanner.
A-61730 August 2012
