4
RECEIVE AND TRANSMIT
D Keyer set mode (continued)

Paddle Polarity

This item sets the paddle dot-dash polarity.

Keyer Type

This item selects the keyer type for [ELEC-KEY] con-
nector on the front panel.
Mic Up/Down Keyer
This item allows you to set the microphone [UP]/[DN]
keys to be used as a paddle.
Normal
• Normal and reverse polarity can be selected.
ELE-KEY
• ELEC-KEY, BUG-KEY and Straight key can be se-
lected. (default: ELEC-KEY)
OFF
• ON : [UP]/[DN] switches can be used for CW.
• OFF : [UP]/[DN] switches cannot be used for
CW.
NOTE: When "ON" is selected, the frequency and
memory channel cannot be changed using
the [UP]/[DN] switches.
4-12
