Handling rolls

Handling rolls
Loading Rolls on the Roll Holder .................................................................................................................................... 507
Loading Rolls in the Printer ............................................................................................................................................... 509
Changing the Type of Paper ............................................................................................................................................ 512
Specifying the Paper Length ............................................................................................................................................ 513
Removing the Roll from the Printer .............................................................................................................................. 514
Removing Rolls From the Roll Holder ........................................................................................................................... 516
Clearing Jammed Roll Paper ..................................................................................................................................... 938
➔
Clearing Jammed Paper (Paper Feed Slot) ......................................................................................................... 944
➔
Feeding Roll Paper Manually ............................................................................................................................................ 517
Keeping Track of the Amount of Roll Paper Left ................................................................................................... 518
Specifying the Ink Drying Time for Rolls .................................................................................................................... 518
Specifying the Cutting Method for Rolls .................................................................................................................... 520
Cutting the Leading Edge of Roll Paper Automatically ........................................................................................ 527
Reducing Dust from Cutting Rolls ................................................................................................................................. 528
Roll Holder Set ........................................................................................................................................................................ 529
Removing the Roll Feed Unit ............................................................................................................................................ 530
Installing the Roll Feed Unit .............................................................................................................................................. 530
Lowering the Up-down Unit of the Spectrophotometer Unit (option) Manually ....................................... 531

Loading Rolls on the Roll Holder

Loading Rolls on the Roll Holder

When printing on rolls, attach the Roll Holder to the roll.
Rolls have a two- or three-inch paper core. Use the correct Holder Stopper and attachment for the paper core.
For borderless printing on A1 (594 mm) or A2 (420 mm) rolls, attach the included Spacer for Borderless Printing to the
Roll Holder.
Using Rolls with a 2-inch Paper Core
Holder Stopper
For 2-inch paper cores
• Set the roll on a table or other flat surface so that it does not roll or fall. Rolls are heavy, and dropping a roll may cause injury.
Caution
User's Guide
Roll Holder Side Holder Stopper
No Attachment Needed For 3-inch paper cores
Loading Rolls on the Roll Holder
Using Rolls with a 3-inch Paper Core
Roll Holder Side
3-Inch Paper Core Attachment
507
