Color Checks Using the Spectrophotometer Unit (option)

When a new Printhead has been installed
•
When a certain amount of printing has been executed after color calibration is executed
•
When the data of color calibration has been initialized
•
To enable the function, set Set Exec. Guide to On on the menu of the Control Panel.
(See "Menu Settings.")
Using the Color Calibration Management Console Management Functions
The Color Calibration Management Console provides the following management functions.
Detailed execution information
•
Execution instructions from the computer
•
Multiple printer management
•
For details, refer to the Color Calibration Management Console instructions.
(See "Color Calibration Management Console (Windows).")
(See "Color Calibration Management Console (Mac OS).")

Color Checks Using the Spectrophotometer Unit (option)

Color Checks Using the Spectrophotometer Unit (option)
Features of Color Checks Using the Spectrophotometer Unit
A color check calculates the difference between the results of color measurement on the pattern built into the printer
and the calibration target.
Executing a color check prints a pattern, which is then measured automatically by the Spectrophotometer Sensor on
the Spectrophotometer Unit.
The resulting measurement value is then compared with the calibration target stored on the printer, and the corre-
sponding difference is displayed on the Control Panel and Color Calibration Management Console.
When printing the color check pattern, the calibration adjustment values are applied even if Use Adj. Value is set to Disabled
•
in the Control Panel menu.
Note
(See "Color Calibration Using the Spectrophotometer Unit (option).")
Setting Threshold Values
Threshold values are used in the Color Check process.
Set in the Color Calibration Management Console.
(See "Executing Color Check (Windows).")
(See "Executing Color Check (Mac OS).")
Executing Color Check from the Control Panel on the Printer
Follow the steps below to execute a Color Check from the Control Panel.
Refer to the information on Color Calibration Management Console operations when executing color check from the
computer.
(See "Executing Color Check (Windows).")
(See "Executing Color Check (Mac OS).")
• Preparing the Printer
1
First, check whether the paper to be loaded can be used in a Color Check.
The types of paper that can be used in Color Checks are the same as those that can be used in Au-
toAdjst(HiPrc) using the Spectrophotometer Unit.
(See "Displaying the Paper Reference Guide.")
