iPF6400S
Cause
Allowing printed documents to dry on top of
each other may cause uneven colors.
Density may be uneven if you use Glossy
Paper or Canon Coated Paper.
The type of paper specified in the printer
driver does not match the type loaded in the
printer.
Colors may be uneven at the trailing edge
when you print on heavyweight sheets even
if you execute Adj Far Ed Feed.
Scan Wait Time > Area in the Control Pan-
el menu is set to Leading edge.
When you load paper in the Front Paper
Feed Slot and print, colors may be uneven
at the leading edge of the paper.

Image edges are blurred or white banding occurs

Image edges are blurred or white banding occurs
Cause
The Platen suction is too strong.
Incorrect Printhead alignment value.
The type of paper specified in the
printer driver does not match the type
loaded in the printer.

Setting the Blue Switch on the Platen

Setting the Blue Switch on the Platen
If printed documents exhibit the following symptoms, adjust the setting of the blue Switch on the Platen.
Image edges are blurred
•
Image edges are affected by white banding
•
User's Guide
To avoid uneven colors, we recommend drying each sheet separately.
In Advanced Settings of the printer driver, choose Highest quality or High in Print Quality.
Load paper of the same type as you have specified in the printer driver.
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Feed Slot.")
Make sure the same type of paper is specified in the printer driver as you have loaded in the
printer.
1.
Press the Stop button and stop printing.
2. Change the type of paper in the printer driver and try printing again.
For heavyweight sheets or similar paper, execute Adj Far Ed Feed with the Front Tray Guides
raised. Also keep the Front Tray Guides raised during printing.
Lower the Front Tray Guides when printing on paper other than heavyweight sheets.
When Scan Wait Time > Area is set to Leading edge, colors may be uneven 110–140 mm from
the leading edge. (The position varies depending on the Print Quality setting.)
In this case, select Scan Wait Time > Area > Entire area.
However, note that printing will now take longer.
(See "Menu Settings.")
P.634
➔
Choose a higher level of Print Quality in the Advanced Settings of the printer driver.
Printing in Fast or Standard mode is faster and consumes less ink than in Highest quality or
High modes, but the printing quality is lower.
(See "Giving Priority to Particular Graphic Elements and Colors for Printing.")
Straighten the paper if it is warped, and then load it straight into the printer.
(See "Loading Sheets in the Feed Slot.")
In the Control Panel menu, reduce the level of VacuumStrngth.
(See "Adjusting the Vacuum Strength.")
Close the blue Switch on the platen so that it matches the paper size.
(See "Setting the Blue Switch on the Platen.")
When printing fine lines or text at high precision on glossy or semi-glossy photo or proofing paper, set
the optimal Printhead height before aligning the printhead.
(See "Enhancing Printing Quality.")
In the Control Panel menu, set Head Height to a lower height.
(See "Troubleshooting Paper Abrasion and Blurry Images.")
Load paper of the same type as you have specified in the printer driver.
(See "Loading Rolls in the Printer.")
(See "Loading Sheets in the Feed Slot.")
Make sure the same type of paper is specified in the printer driver as you have loaded in the printer.
1. Press the Stop button and stop printing.
2.
Change the type of paper in the printer driver and try printing again.
Image edges are blurred or white banding occurs
Corrective Action
P.509
➔
P.533
➔
P.533
➔
Corrective Action
P.777
➔
P.955
➔
P.762
➔
P.769
➔
P.509
➔
P.533
➔
P.59
➔
