THE TWO MINUTE USER'S GUIDE
The instructions on this page will help you get your UT Series system up
and running in minutes. For more detailed instructions, read the section of
this manual that applies to your system.

RECEIVER SETUP

1. Connect the supplied ac power adapter to the DC INPUT connector on the back of
the receiver. Insert the adapter's cable into the power cable retainer on the bottom
of the unit. Plug the adapter into a wall socket or other electrical outlet. The green
POWER light on the receiver will glow.
2. If you are using The Guitarist-UHF , connect the receiver output to a guitar am-
plifier using any standard guitar cable. If you are using The Vocal Artist-UHF ,
The Headset-UHF , or The Presenter-UHF , connect the receiver output to an
audio mixer using an XLR to XLR audio cable.
3. Raise the antennas and point away from each other at a 45 angle from vertical.

TRANSMITTER SETUP

1. Open the transmitter battery compartment and install a 9 V battery. Observe proper
battery polarity ("+/–").
2. If you are using The Vocal Artist-UHF, no further transmitter setup is required.
3. If you are using a body-pack transmitter (The Presenter-UHF, The Headset-UHF
or The Guitarist-UHF), plug the microphone cable or a WA302 instrument cable
into the four-pin connector on the transmitter (if using The Headset-UHF, see tag
on headset for assembly instructions). If using The Guitarist-UHF, plug the instru-
ment cable into the guitar output and adjust the volume control of the guitar.

OPERATING THE SYSTEM

1. Slide the transmitter POWER/OFF switch to the POWER position. The transmitter's
green POWER light and the receiver's yellow DIVERSITY A/B lights will glow.
2. Slide the MUTE/ON switch on the body-pack or hand-held transmitter to the ON
position.
3. Talk or sing into the microphone, or play your guitar. The receiver's red AUDIO PEAK
light should flicker when loud sounds are transmitted. If the AUDIO PEAK light does
not flicker or stays on constantly, the transmitter gain may need adjustment. (Refer
to the Transmitter Audio Gain Adjustment section). NOTE: This step is particularly
important for The Guitarist system, since guitar outputs can vary widely.
4. Adjust the receiver VOLUME control until the receiver output level matches the
level of your guitar or microphone through a cable. (The factory setting is in the
full clockwise position.) If using The Guitarist-UHF system, see Receiver Volume
Adjustment for The Guitarist-UHF to match the receiver volume level to the level
of a wired system.
IMPORTANT: Every wireless performance is a unique situation, and can present a vari-
ety of problems. Never attempt a performance without first conducting a "walkthrough"
test on the wireless system in the performing area. If you encounter a problem, refer
to the Troubleshooting table.
YOU ARE NOW READY TO PERFORM!
