- Page 1 TEC Ink Jet Printer BRST-10 SERIES Owner’s Manual Table of Contents...
- Page 2 Changes or modifications not expressly approved by the manufacturer for compliance could void the user’s authority to operate the equipment. Copyright © 2000 by TOSHIBA TEC CORPORATION All Rights Reserved 570 Ohito, Ohito-cho, Tagata-gun, Shizuoka-ken, JAPAN...
-
Page 3: Safety Summary
Do not attempt to effect repairs or modifications to this equipment. If a fault occurs that cannot be rectified using the procedures described in this manual, turn off the power, unplug the machine, then contact your authorized TOSHIBA TEC representative for assistance. Meaning of Each Symbol This symbol indicates warning items (including cautions). - Page 4 • Utilize our maintenance services. After purchasing the machine, contact your authorized TOSHIBA TEC representative for assistance once a year to have the inside of the machine cleaned. Otherwise, dust will build up inside the machines and may cause a fire or a malfunction. Cleaning is particularly effective before humid rainy seasons.
-
Page 5: Table Of Contents
CAUTION: 1. This manual may not be copied in whole or in part without prior written permission of TOSHIBA TEC. 2. The contents of this manual may be changed without notification. 3. Please refer to your local Authorized Service representative with regard to any queries... -
Page 6: Introduction
EO1-13013 1.1 APPLICABLE MODEL 1. INTRODUCTION Thank you for purchasing the TEC BRST-10 Series 1.5 Station bubble jet Printer. This printer is a high- speed and high-quality bubble jet printer. The interface complies with the Serial interface (conforming to RS-232C). -
Page 7: Specifications
2. SPECIFICATIONS EO1-13013 2.1 PRINTER 2. SPECIFICATIONS 2.1 PRINTER Model BRST-10-1SF-QM Item +24 V DC – 5 % (Recommended Power Adapter : PS-10-QM) Supply voltage 1.5 A maximum Current consumption 5 C to 35 C Operating temperature 10 % to 85 % RH (no condensation applies to the printer, not the paper) Relative humidity Serial bubble jet Printing methods... -
Page 8: Receipt Paper
2. SPECIFICATIONS EO1-13013 2.2 RECEIPT PAPER 2.2 RECEIPT PAPER 71.1 Maximum Logo Print Area 36.1 NOTE: All dimensions are shown in 56.6 millimeters. 4.23 71.1 (42 digits) 2.45 2.45 Fig. 2-1 Type White slick paper Weight 54.3 –2 g/m Thickness 0.083 –... -
Page 9: Overview
3. OVERVIEW EO1-13013 3.1 FRONT/REAR VIEW 3. OVERVIEW 3.1 FRONT/REAR VIEW Front View Printer Cover Slip Inlet Front Cover Receipt Outlet Operation Panel Fig. 3-1 Rear View Paper Cover Drawer Interface Connector DC Power Inlet Serial Interface Connector (RS-232C) Fig. 3-2... -
Page 10: Operation Panel
3. OVERVIEW EO1-13013 3.2 OPERATION PANEL 3.2 OPERATION PANEL 1 1 1 1 1 POWER LED (Green) Power is supplied. Off: Power is not supplied. Blinking: Ink is being initial operation when the power turns ON. 2 2 2 2 2 SLIP LED (Green) Slip mode Off: Receipt mode... -
Page 11: Set Up Procedure
• To communicate with the ECR or POS terminal, an RS-232C cable is required. RS-232C cable ....25 pins Interface Cables Use the serial printer cable CBLST-50-2-QM supplied by TOSHIBA TEC or its equivalent. To prevent radiation and reception of electrical noise, the interface cables must meet the following requirements: •... -
Page 12: Installation Procedure
CAUTION: 1. Do not put anything on the printer cover and never press on it. 2. Use only TOSHIBA TEC specified paper. Use of non-specified paper may lower the print quality or shorten the cutter life. 3. Set the receipt roll in the correct direction. Failure to do this may cause a paper jam error. -
Page 13: Loading The Head Unit/ Ink Cartridge
5. INSTALLATION PROCEDURE EO1-13013 5.2 LOADING THE HEAD UNIT/ INK CARTRIDGE 5.2 LOADING THE HEAD UNIT/ INK CARTRIDGE 1. Open the printer cover while holding the handle, and remove it. Printer Cover CAUTION Do not put anything on the cover and never press it. - Page 14 5. INSTALLATION PROCEDURE EO1-13013 5.2 LOADING THE HEAD UNIT/ INK CARTRIDGE 3. Unpack a head unit/ ink cartridge. Remove the protection pad from the head unit/ ink cartridge. 1 4. Remove the protection sheet from the head unit/ ink cartridge. 2 NOTES: 1.
-
Page 15: Loading The Receipt Roll
5. INSTALLATION PROCEDURE EO1-13013 5.3 LOADING THE RECEIPT ROLL 6. Depress the [CARTRIDGE] switch. The printer performs the initial operation. After the initial operation is finished, the carriage returns to the home position (right end). 7. Insert the two hooks into the holes on the top cover, and then close the printer cover slowly. Printer Cover Hooks Top Cover... - Page 16 5. INSTALLATION PROCEDURE EO1-13013 5.3 LOADING THE RECEIPT ROLL 3. Load the receipt roll into the paper holder as the figure shows. 2 Receipt Roll NOTE: Set the receipt roll in correct direction. Paper Cover Cut the paper end to make it sharp.
-
Page 17: Inserting The Slip
5. INSTALLATION PROCEDURE EO1-13013 5.4 INSERTING THE SLIP 5.4 INSERTING THE SLIP 1. When the host sends the slip print command to the printer, the SLIP LED blinks. 2. Insert the slip straight into the slip inlet while aligning the right side of the slip with the slip inlet. -
Page 18: Replacing The Receipt Roll
CAUTION: 1. Use only TOSHIBA TEC specified paper. Use of non-specified paper may lower the print quality or shorten the cutter life. 2. Set the receipt roll in the correct direction. Failure to do this may cause a paper jam error. - Page 19 6. REPLACING THE RECEIPT ROLL EO1-13013 6. REPLACING THE RECEIPT ROLL 5. Pull up the rear paper release lever (blue). 4 6. Push down the front paper release lever in direction 5, and then remove the receipt roll in direction 6. Rear Paper Release Lever (blue) Fig.
-
Page 20: Replacing The Ink Cartridge
7. REPLACING THE INK CARTRIDGE EO1-13013 7. REPLACING THE INK CARTRIDGE 7. REPLACING THE INK CARTRIDGE The INKOUT LED on or blinking shows that ink is getting low. The printer can print until ink is fully finished, however, please replace the ink cartridge with a new one earlier. WARNING! 1. - Page 21 7. REPLACING THE INK CARTRIDGE EO1-13013 7. REPLACING THE INK CARTRIDGE 4. Unpack a new ink cartridge. Pull down both arrow sections remove the protection pad from the cartridge. NOTES: 1. Do not touch the ink outlet on the bottom of the ink cartridge with your fingers or any objects.
-
Page 22: Replacing The Head Unit/ Ink Cartridge
8. REPLACING THE HEAD UNIT/ INK CARTRIDGE EO1-13013 8. REPLACING THE HEAD UNIT/ INK CARTRIDGE 8. REPLACING THE HEAD UNIT/ INK CARTRIDGE If the head unit gets dirty or a dot missing occurs, clean the head unit. (Refer to 9.1 CLEANING) If these phenomena still remain, replace the head unit/ ink cartridge with a new one by the following procedure. - Page 23 8. REPLACING THE HEAD UNIT/ INK CARTRIDGE EO1-13013 8. REPLACING THE HEAD UNIT/ INK CARTRIDGE 5. Unpack a new head unit/ ink cartridge. Remove the protection pad from the head unit/ ink cartridge. 1 6. Remove the protection sheet from the head unit/ ink cartridge. 2 NOTES: 1.
-
Page 24: General Maintenance
9. GENERAL MAINTENANCE EO1-13013 9.1 CLEANING 9. GENERAL MAINTENANCE WARNING! 1. Be sure to disconnect the power cord prior to performing any maintenance. 2. Do not use any tool that may damage the head unit. 3. DO NOT POUR WATER directly onto the printer. CAUTION: 1. -
Page 25: Troubleshooting
10. TROUBLESHOOTING 10. TROUBLESHOOTING WARNING! If you cannot solve a problem with the following solutions, do not attempt to repair it yourself. Turn the power off, unplug the printer, then contact your TOSHIBA TEC representative for assistance. Check Point Solution Symptom •... -
Page 26: Error Message
NOTE: In case other combination of LEDs except for the above light or blink, turn the power off, and then turn the power on. If this does not restore the LEDs, contact your nearest TOSHIBA TEC representative for assistance. 11-1...
