Page 1
Meijer.com 1575 Stainless Steel Gas Grill Parrilla de Gas de Acero Inoxidable OWNER’S MANUAL / MANUAL DEL PROPIETARIO ASSEMBLY AND OPERATING INSTRUCTIONS INSTRUCCIONES DE ARMADO Y OPERACIÓN SAVE THIS MANUAL FOR FUTURE REFERENCE GUARDE ESTE MANUAL PARA REFERENCIA FUTURA WARNING/ADVERTENCIA NOTICE TO INSTALLER: HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS LEAVE THESE INSTRUCTIONS...
Page 2
Meijer.com IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
Meijer.com GENERAL WARNINGS WARNING • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. •...
Meijer.com WARNING • FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors.
Page 6
Meijer.com CYLINDER SPECIFICATIONS: When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;...
Meijer.com WARNING FILLING THE LP GAS CYLINDER: • Allow only qualified LP gas dealers to properly fill or repair your LP gas cylinder. • New tanks should be purged prior to filling; inform LP gas dealer if you are using a new tank. •...
Page 8
Meijer.com WARNING • Never use your grill without leak testing all gas connections and hoses. See the section on "Leak Testing" in this manual for proper procedures. WARNING The pressure regulator and hose assembly supplied with your gas grill must be used. •...
Meijer.com DANGER LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •...
Meijer.com 6. Check each place listed (A–J) for growing bubbles which indicates a leak. 7. Turn off gas supply at cylinder valve. 8. Turn on control knobs to release gas pressure in hose. 9. Turn control knobs to "OFF" position. 10.
Meijer.com WARNING Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections of this manual. WARNING LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill.
Page 12
Meijer.com LIGHTING THE ROTISSERIE BURNER: 1. Open grill hood before lighting rotisserie burner. 2. Make sure control knob is in the "OFF" position. 3. Push and turn the control knob to the "HIGH" position. Press electronic igniter for 3 – 5 seconds. 4.
Page 13
Meijer.com MATCH LIGHTING THE SEAR BURNER: 1. Open the lid to the sear burner before lighting. 2. Make sure control knob is in the "OFF" position. 3. Strike and carefully place a match approximately 1/2" (1 to 2 cm) from the sear burner. Push and turn the sear burner control knob to the "HIGH"...
Meijer.com WARNING OPERATING THE GRILL: Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. Read and follow all warnings and instructions contained in the preceding sections of this manual. BREAKING IN YOUR GRILL: •...
Meijer.com ROTISSERIE COOKING: • Your grill was pre-drilled from factory to include mounting holes for a rotisserie sold separately. Do not use a rotisserie not specifically manufactured for this grill. • Read and follow all instructions provided with the rotisserie. Save instructions for future reference. •...
• To protect your grill from excessive rust, the unit must be kept clean and covered at all times when not in use. A grill cover may be ordered directly from Brinkmann by calling 800-468-5252 or 800-527-0717. • Wash cooking grills and heat distribution plates with hot, soapy water, rinse well and dry. Lightly coat cooking grill with vegetable oil or vegetable oil spray.
Meijer.com CLEANING AND MAINTENANCE: • Keep the appliance free and clear of combustible materials, gasoline and other flammable vapors and liquids. • Keep the ventilation openings of the cylinder enclosure free and clear of debris. • Visually check burner flames for proper operation (see pictorial in "Burner Assembly/Maintenance" under Proper Care and Maintenance).
Meijer.com BURNER ASSEMBLY/MAINTENANCE CONTINUED Note: Follow the "Gas Leak Testing" section of this manual. Relight burners to verify proper operation. 12. Replace heat distribution plates and cooking grills. PROPER BURNER OPERATION COOKING GRILLS • Clean with mild soap detergent and water. A brass bristled brush or a nylon cleaning pad can be used to remove residue from the stainless steel surfaces.
Meijer.com BEFORE STORING YOUR GRILL: • Ensure that the cylinder valve is fully closed. • Clean all surfaces. • Lightly coat the burners with cooking oil to prevent excess rusting. • If storing the grill indoors, disconnect the LP tank and leave the LP tank OUTDOORS. •...
If the fuel line is blocked, replace with a new hose / regulator assembly. • If an obstruction is suspected in the hose / regulator assembly, orifice or gas valves call Brinkmann Customer Service at 800-527-0717. Question: Why does my LP gas grill have a low flame or a flame with orange / yellow color? Answer: You need to purge air from the gas line or reset the regulator's flow limiting device.
Regulator Resetting Procedure under Connecting LP Cylinder and Hose/Regulator to Grill. This procedure should be done every time a new LP gas tank is connected to your grill. For help, refer to your owner’s manual or call Brinkmann Customer Service at 800-527-0717.
Meijer.com PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. PARTS BAG CONTAINS: Qty. 28 M6 X 12 mm Bolts (Black) Plastic Rivets M6 X 12 mm Bolts (Silver) Screwdriver 10 M4 X 10 mm Bolts (Black) Hex Nut Wrench...
Meijer.com ASSEMBLY INSTRUCTIONS READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT. The following provided tools are required to assemble this ProSeries™ 1575 Gas Grill: •...
Page 24
Meijer.com FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: Inspect contents of the box to ensure all parts are included and undamaged.
Page 25
Meijer.com Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay cardboard down to protect grill finish and assembly area. CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary. Step 1 Attach cart base to side panels.
Page 26
Meijer.com Step 4 Attach door bracket to left and right leg of cart using six M6 X 12 mm bolts (black). Step 5 Attach tank holder onto cart base by using three plastic rivets. Note: With the help of a friend, turn the cart over.
Page 27
Meijer.com Step 7 Use two #8 self-tapping screws (black) to attach the rear cart brace/tank heat shield to rear legs. Heat shield will rest on upper door bracket. Lower Left/Upper Right Door Hinges Step 8 Install the door hinge as shown using two M4 X 10 mm bolts.
Page 28
Meijer.com Spring Pin Step 10 Insert right side door pivot into lower pivot hole (on bottom cart shelf) then align door with cart frame. Depress spring pin located on top edge of door and slide door toward side cart panel until spring pin locks into hole in door bracket.
Page 29
Meijer.com Step 12 Insert the bolt with pre-attached nut on the side table into the key holes on the side table front panel. Tighten the nut with wrench. Insert two M6 X 12 mm bolts from side table to side table front panel and tighten securely.
Page 30
Meijer.com Step 14 Attach side table to left side of cart frame assembly. Place table over pre-attached bolts and slide toward back of grill, then tighten securely Fasten side table front panel to grill body with one M6 X 12 mm bolt (silver).
Page 31
Meijer.com Step 17 Press the two raised points on the back of the bezel into the corresponding holes on the sear burner front panel. Then, firmly seat the valve nozzle into the burner venturi. Hold in place while you perform Step 18. Side Table Holes Step 18 Insert the two screws that are...
Page 32
Meijer.com Step 21 Place the sear burner grate Sear Burner as illustrated. Install the sear burner Grate control knob onto valve stem. Sear Burner Control Knob Bezel Electrodes Step 22 Attach electrode wire to the igniter wire as illustrated. Electrode Wire Igniter Wire Wind Deflectors Step 23...
Page 33
Meijer.com Step 25 Insert the sear burner grease tray on tracks under sear burner in back. Sear Burner Grease Tray Step 26 Remove igniter cap and insert battery with positive end of battery toward igniter cap. Ensure spring is in place inside igniter cap. Replace igniter cap and make sure the igniter is working properly.
Page 35
Meijer.com IMPORTANTES ADVERTENCIAS DE SEGURIDAD ES NUESTRO DESEO QUE ARME Y UTILICE SU PARRILLA EN LA FORMA MÁS SEGURA POSIBLE. EL PROPÓSITO DE ESTE SÍMBOLO DE ALERTA DE SEGURIDAD ES QUE USTED PRESTE ATENCIÓN A LOS POSIBLES PELIGROS CUANDO ARME Y UTILICE SU PARRILLA.
Page 36
Meijer.com ÍNDICE Advertencias generales ............36 Instalación, especificaciones y uso seguro del cilindro de propano líquido .
Meijer.com ADVERTENCIAS GENERALES ADVERTENCIA • Nunca use gas natural en una unidad diseñada para gas de propano líquido. • Nunca use briquetas de carbón en una parrilla de gas. Los pedacitos de madera para dar sabor se deben colocar en una cajita de fumar de metal para contener la ceniza y para prevenir fuegos. •...
Meijer.com ADVERTENCIA • PARA USO EXTERIOR ÚNICAMENTE. NO opere la parrilla en áreas interiores o en un área cerrada como un garaje, cobertizo o pasadizo. • Use la parrilla AL AIRE LIBRE en un espacio bien ventilado alejado de viviendas u otros edificios para prevenir los peligros asociados con la acumulación de gas y los vapores tóxicos.
Page 39
Meijer.com ESPECIFICACIONES DEL CILINDRO Cuando compre o cambie un cilindro para la parrilla de gas, debe estar construido y marcado de acuerdo con las especificaciones para cilindros de gas de propano líquido del Departamento de Transporte (DOT) de EE.UU. o la Norma Nacional de Canadá, CAN/CSA-B339: Cilindros, esferas y tubos para el transporte de artículos peligrosos;...
Meijer.com ADVERTENCIA LLENADO DEL CILINDRO DE GAS DE PROPANO LÍQUIDO: • Sólo los distribuidores de gas de propano líquido capacitados deben llenar o reparar su cilindro. • Los tanques nuevos deben ser purgados antes de llenarlos; dígale al distribuidor de gas que está usando un tanque nuevo.
Page 41
NO use ningún otro conjunto de regulador de presión/manguera que no sea el suministrado con la parrilla. El número de parte del conjunto de regulador de presión/manguera de repuesto debe ser Brinkmann Nº 155-1575-0 y puede obtenerse comunicándose con Brinkmann al 800-527-0717.
Meijer.com PELIGRO PRUEBAS DE DETECCIÓN DE FUGAS: Para impedir los peligros de incendio o explosión: • NO fume ni permita que haya fuentes de encendido en el área mientras realiza la prueba de detección de fugas. • Realice la prueba AL AIRE LIBRE únicamente, en un área bien ventilada. •...
Meijer.com 6. Inspeccione cada uno de los elementos indicados (A-J) para ver si hay burbujas, lo cual indica una fuga. 7. Cierre el suministro de gas en la válvula del cilindro. 8. Gire las perillas de control para descargar la presión de gas en la manguera. 9.
Meijer.com ADVERTENCIA Lea, entienda y siga todas las advertencias e instrucciones indicadas en este manual. NO pase por alto ninguna de las advertencias o instrucciones indicadas en las secciones anteriores de este manual. ADVERTENCIA INSTRUCCIONES DE ENCENDIDO: Siga las instrucciones al pie de la letra. ABRA LA TAPA DE LA PARRILLA antes de tratar de encender una hornilla para que no se acumulen vapores dentro de la parrilla.
Page 45
Meijer.com ENCENDIDO DE LA HORNILLA ROTISSERIE 1. Abra la tapa antes de encender la hornilla de rotisserie. 2. Verifique que la perilla de control esté en la posición "APAGADO". 3. Empuje y gire la perilla de control a la posición "ALTO". Oprima el encendedor electrónico durante 3 a 5 segundos .
Page 46
Meijer.com ENCENDIDO DE LA HORNILLA PARA DORAR CON UN CERILLO: 1. Abra la tapa de la hornilla para dorar antes de encenderla. 2. Verifique que la perilla de control esté en la posición "APAGADO". 3. Prenda y coloque con cuidado un cerillo aproximadamente a 1/2 pulgada (1 a 2 cm) de la hornilla para dorar.
Meijer.com ADVERTENCIA OPERACIÓN DE LA PARRILLA: Nunca use briquetas de carbón en una parrilla de gas. Los pedacitos de madera para dar sabor se deben colocar en una cajita de fumar de metal para contener la ceniza y para prevenir fuegos. Lea y siga todas las advertencias e instrucciones indicadas en las secciones anteriores de este manual.
Page 48
Meijer.com COCCIÓN ESTILO ROTISSERIE: • La parrilla viene preparada de la fábrica con agujeros de montaje para instalar un asador estilo rotisserie (vendido aparte). No use un asador estilo rotisserie que no haya sido fabricado especialmente para esta parrilla. • Lea y siga todas las instrucciones incluidas con el asador estilo rotisserie.
Utilice un termómetro para carne para verificar que haya alcanzado una temperatura interna segura. Puede ordenar un termómetro de calidad comercial de Brinkmann. Para obtener más información sobre este producto y otros accesorios Brinkmann, consulte las páginas de accesorios al final de este manual. •...
Meijer.com LIMPIEZA Y MANTENIMIENTO: • Mantenga el artefacto alejado de materiales combustibles, gasolina u otros vapores o líquidos inflamables. • Mantenga los orificios de ventilación del gabinete del cilindro sin residuos. • Observe las llamas de las hornillas para verificar que estén funcionando bien (consulte el dibujo en "Instalación/Mantenimiento de las Hornillas"...
Meijer.com CONTINUACION DE INSTALACIÓN/MANTENIMIENTO DE LAS HORNILLAS Nota: Siga la sección “Verificación de Ausencia de Fugas” de este manual. Vuelva a encender las hornillas para verificar la operación apropiada) 12. Reinstale las placas de distribución del calor y las rejillas para cocinar. OPERACION APROPIADA DE HORNILLA REJILLAS PARA COCINAR •...
Meijer.com ANTES DE GUARDAR LA PARRILLA: • Verifique que la válvula del cilindro está bien cerrada. • Limpie todas las superficies. • Aplique una capa ligera de aceite para cocinar a las hornillas para evitar la oxidación excesiva. • Si va a guardar la parrilla en un área interior, desconecte el tanque de propano líquido y déjelo AFUERA.
El número de modelo y número de serie de la parrilla y la información para contactarse con el Servicio de atención al cliente de Brinkmann se incluyen en una etiqueta plateada abajo del panal de control o en el costado de la caja de la misma, debajo del estante lateral y tambien atras del assador en el panal.
Page 54
"Conexión del cilindro de propano líquido y de la manguera / regulador a la parrilla. Se debe seguir este procedimiento cada vez que se conecte un nuevo tanque de gas de propano líquido a la parrilla. Si necesita ayuda, consulte el manual del propietario o llame al Servicio de atención del cliente de Brinkmann al 800-527-0717.
Meijer.com CONTENIDO DE LA BOLSA DE PARTES Verifique que tiene todos los artículos indicados en la LISTA DE PARTES y en el CONTENIDO DE LA BOLSA DE PARTES antes de comenzar con el proceso de instalación. La bolsa de partes incluirá lo siguiente: Cant.
Page 56
Meijer.com INSTRUCCIONES DE ARMADO LEA DETENIDAMENTE TODAS LAS ADVERTENCIAS DE SEGURIDAD E INSTRUCCIONES ANTES DE ARMAR Y USAR LA PARRILLA RECOMENDAMOS QUE ESTA UNIDAD SEA ARMADA POR DOS PERSONAS Se necesitan las siguientes herramientas incluidas para armar esta Parrilla de Gas ™...
Page 57
Meijer.com PARA CUBIERTAS, ACCESORIOS Y OTROS PRODUCTOS, FAVOR DE VISITARNOS POR LA RED MUNDIAL Inspeccione el contenido de la caja para verificar que todas las partes estén incluidas e intactas.
Page 58
Meijer.com Elija un lugar adecuado y despejado para armar la parrilla y pídale a un amigo que le ayude. Tienda cartón sobre el suelo para proteger el acabado de la parrilla y el área de armado. PRECAUCIÓN: Algunas partes pueden tener bordes afilados.
Page 59
Meijer.com Paso 4 Ate el soporte de la puerta a la pierna izquierda y derecha del carro usando seis pernos M6 X 12 mm (negros). Paso 5 Ate el soporte para el tanque a la base del carro con tres remaches de plástico.
Page 60
Meijer.com Paso 7 Utilice dos tornillos autoroscantes #8 (negro) para atar el escudo térmico posterior del apoyo/del tanque del carro a las piernas posteriores. El escudo térmico se reclinará sobre el soporte superior de la puerta. Paso 8 Bisagras Superiores Izquierda / Inferiores Derecha de la Puerta Instale la bisagra de puerta como se muestra usando dos pernos...
Page 61
Meijer.com Pasador de Resorte Paso 10 Inserte el pivote de la puerta derecha dentro el agujero inferior (ubicado en el estante inferior del carro) alinee la puerta con el marco del carro. Presione el pasador con resorte hacia abajo localizado en el borde superior de la puerta y resbale la puerta hace el panel del carro hasta que el pasador con resorte se trabe...
Page 62
Meijer.com Paso 12 Inserte el perno con la tuerca pre- atada en la mesa lateral en los agujeros dominantes en el panel delantero lateral de la mesa. Apriete la tuerca con la llave. Inserte dos pernos M6 X12 mm de la mesa lateral al panel delantero lateral de la tabla y apriete con seguridad.
Page 63
Meijer.com Paso 14 Ate la mesa lateral al lado izquierdo del conjunto del carro. Coloque la mesa sobre los pernos pre atados y resbale hacia la parte posterior de la parrilla, después apriete con seguridad. Sujete el panel frontal de la mesa lateral al cuerpo de la parrilla usando un perno M6 X 12 mm (plateado).
Page 64
Meijer.com Paso 17 Presione los dos puntos levantados en la parte posterior del bisel dentro de sus correspondientes orificios en el panel frontal del quemador lateral. Luego, firmemente asiente la boquilla de la válvula dentro del venturi del quemador. Manténgalo en su lugar Orificios de la Mesa Lateral mientras realiza el Paso 18.
Page 65
Meijer.com de la Rejilla del Paso 21 Hornilla para Coloque la rejilla de de la hornilla Dorar para dorar según lo ilustrado. Instale la perilla de control d de la hornilla Perilla de para dorar sobre el vástago de la de la Control válvula.
Page 66
Meijer.com Paso 25 Inserte la bandeja para la grasa de la hornilla para dorar en la apertura en la parte trasera de la parrilla. Bandeja para de la la Grasa Hornilla para Paso 26 Dorar Quite la tapa del encendedor e inserte la pila con su polo positivo apuntando hacia la tapa del encendedor.
Page 68
Esta garantía se otorga al comprador original únicamente y no es transferible o asignable a los compradores posteriores. The Brinkmann Corporation exige un comprobante de compra razonable. Por lo tanto, le recomendamos enfáticamente que retenga su recibo o factura de ™...
