MEDALLION
5 Burner Gas Grill
ASSEMBLY AND OPERATING IN STRUC TIONS
INSTRUCCIONES DE ARMADO Y OPERACIÓN
SAVE THIS MANUAL FOR FUTURE REFERENCE
Model / Modelo 810-4580-S
HAZARDOUS EXPLOSION MAY RESULT IF THESE WARNINGS AND INSTRUCTIONS
ARE IGNORED. READ AND FOLLOW ALL WARNINGS AND INSTRUCTIONS IN THIS
MANUAL TO AVOID PERSONAL INJURY, INCLUDING DEATH OR PROPERTY DAMAGE.
SE PUEDE PRODUCIR UNA EXPLOSIÓN PELIGROSA SI SE HACE CASO OMISO A
ESTAS ADVERTENCIAS E INSTRUCCIONES. LEA Y SIGA TODAS LAS ADVERTENCIAS
E INSTRUCCIONES EN ESTE MANUAL PARA EVITAR LESIONES PERSONALES,
Read Instructions
Before Lighting:
1. Open lid during lighting.
2. Select a burner to be lit. Push
and turn control knob of that
burner to "HIGH." Press
electronic igniter and hold for
3-5 seconds.
3. If ignition does not occur in
5 seconds, turn control knob
to "OFF," wait 5 minutes and
repeat lighting procedure.
LIGHTS
LUCES
WARNING/ADVERTENCIA
INCLUSO LA MUERTE, O LOS DA—OS MATERIALES.
300
400
200
500
100
600
FOR OUTDOOR
Lea las Instrucciones
USE ONLY
Antes de Iluminación:
SOLAMENTE PARA
1. Abra la tapa durante el
USO EN EXTERIORES
encendimiento.
2. Seleccione la hornilla que va a
encender. Empuje y gire la
perilla de control de esa
hornilla a la posición "ALTO".
Oprima el encendedor
electrónico
y manténgalo oprimido
3 a 5 segundos.
3. Si la hornilla NO se enciende
en 5 segundos, gire la perilla
de control a la posición
"APAGADO"espere 5 minutos y
repita el procedimiento de
encendido.
800-527-0717
For Accessories, Parts or Assistance, Call
NG Conversion
or Visit our Website
Kit Required
Para Accesorios, Partes o Asistencia,
Kit de la Conversión
del NG Requerido
Llame o Visite Nuestro Sitio de Internet
Sear Burner Lighting Instructions:
SEAR BURNER
1. Open lid during lighting.
HORNILLA PARA
2. Push and turn control knob to "HIGH" and continue to push in.
DORAR
3. Press electronic igniter and hold for 3 to 5 seconds.
4. Continue to push in control knob for 30 seconds after sear burner is lit.
5. If ignition does not occur in 5 seconds, turn control knob to "OFF," wait 5
minutes and repeat lighting procedure.
Instrucciones de Iluminación para la Hornilla
para Dorar:
1. Abra la tapa durante el encendimiento.
2. Empuje la perilla de control y gire a la posición "ALTO" y continúe
empujando hacia adentro.
MAXIMUM SEAR BURNER
3. Presione el encendedor electrónico y sosténgase por 3 a 5 segundos.
WEIGHT = 15 lbs.
4. Continúe empujando la perilla de control hacia adentro por
30 segundos después de que la hornilla para dorar se enciende.
PESO MÁXIMO DE LA HORNILLA
5. Si la hornilla NO se enciende en 5 segundos, gire la perilla de control a la
PARA DORAR = 6.8 kg
posición "APAGADO", espere 5 minutos y repita el procedimiento de
encendido.
ELECTRONIC
IGNITER
ENCENDEDOR
ELECTRÓNICO
