- Page 1 40005508.qxd 05/03/2008 09:49 Page 1 Instruction Book HNL 662 HNL 642 ®...
-
Page 2: Table Of Contents
40005508.qxd 05/03/2008 09:49 Page 2 Contents Introduction ........3 Delivery information . -
Page 3: Introduction
40005508.qxd 05/03/2008 09:49 Page 3 Introduction Check that no damage has occurred to the machine during transit. Please read and follow these instructions carefully and If it has, call for service operate the machine accordingly. This booklet provides important guidelines for safe use, installation, maintenance by GIAS. -
Page 4: Unpacking The Product
40005508.qxd 05/03/2008 09:49 Page 4 Unpacking the product Remove the machine from its packaging close to the final location of the machine. Cut carefully around the base of the packaging. Lay the machine on its back and remove the base and the two polystyrene spacers on each side of the machine. - Page 5 40005508.qxd 05/03/2008 09:49 Page 5 Remove the four retaining screws in the transit bar and pull out the transit bracket. We recommend you keep the transit bracket and screws to protect the machine for future transit. The manufacturers will not be responsible for any damage to the machine caused by not following the instructions relating to releasing the transit protection.
- Page 6 40005508.qxd 05/03/2008 09:50 Page 6 Take the two plastic fixing clips and fix the base panel to the base of the machine. Bring the machine back to the upright position. Cover the central hole in the rear of the machine with the cap enclosed in the instruction bag.
-
Page 7: Installation
40005508.qxd 05/03/2008 09:50 Page 7 Installation Choose a location Do not plug the machine in and switch ● After the machine has been installed, ensure that the mains plug and water supply valves are easily accessible. it on at the mains until the installation is ●... -
Page 8: Connecting To The Cold Water Supply
40005508.qxd 05/03/2008 09:50 Page 8 Connecting to the cold water supply Only one hose is required to install this machine to a cold This Appliance water supply. Cold fill is an energy efficient system. Only the water required must be to wash the laundry is heated. -
Page 9: Connection Of The Machine To The Drain
40005508.qxd 05/03/2008 09:50 Page 9 Connection of the machine to the drain This machine must be connected in accordance with the water supply regulations. Water byelaws prohibit connection to a surface water drain. Decide which plumbing option suits you best then follow the instructions below. All machines are tested with water prior to leaving the factory so a small amount of water may remain in the drum and drain hose. -
Page 10: Moving The Machine Into Position
40005508.qxd 05/03/2008 09:50 Page 10 Moving the machine into position Your machine is heavy so care must be taken when moving it. Do not drag or lift the We recommend that two people move the machine to avoid strain and possible injury. machine by its door. -
Page 11: Testing The Installation
40005508.qxd 05/03/2008 09:50 Page 11 Testing the installation Refer to ‘Selecting the wash programme’ for details of how to select programmes. Turn on the water supply and check for leaks from the fill hose. Switch on the electricity supply. Select the Spin programme and then press the Start Pause button to start the machine. -
Page 12: Washing Advice
40005508.qxd 05/03/2008 09:50 Page 12 Washing advice The following tips are designed to assist in getting the best results from your machine whilst using it in the most environmentally-friendly and economical way. It is also important to understand the items to avoid in your laundry, to ensure the continued safe and reliable operation of your machine. -
Page 13: Sorting The Laundry
40005508.qxd 05/03/2008 09:50 Page 13 Sorting the laundry Items to avoid We recommend that you do not wash underwired bras in the Do not use the machine machine. Should the wires become detached they could cause to wash items that do damage to your clothes and the machine. -
Page 14: The Dispenser
40005508.qxd 05/03/2008 09:50 Page 14 The Dispenser COMPARTMENT COMPARTMENT I Fabric Conditioner Prewash detergent Maximum dosage 200ml Maximum dosage 100ml of powder COMPARTMENT II Mainwash detergent Maximum dosage 200ml of powder Detergent dosage Only use detergents which are suitable for use in a washing DO NOT exceed machine. -
Page 15: Dispensing Instructions
40005508.qxd 05/03/2008 09:50 Page 15 Dispensing instructions Do not put any items into the drawer other The detergent drawer is split into 3 compartments: than detergents that ● the lefthand compartment, labelled "II", is for detergent are designed to be utilised during the main wash. -
Page 16: The Control Panel
40005508.qxd 05/03/2008 11:05 Page 16 The Control Panel Countdown Display START OPTION TEMPERATURE PROGRAMME SELECTOR PAUSE BUTTONS SELECTOR Turning the machine On The programme Turn the machine ON by selecting a programme using the selector must be return programme selector. This status will be indicated by the STOP to the OFF position to indicator light flashing, this light will continue to flash until reset the controls... - Page 17 40005508.qxd 05/03/2008 09:50 Page 17 seconds. When the machine is in the paused mode, the time remaining for the programme in the countdown display indicator and option buttons will flash. The door lock indicator light will remain illuminated for approximately 2 minutes. The door can be opened when this indicator goes out.
-
Page 18: Wash Options
40005508.qxd 05/03/2008 09:50 Page 18 Wash Options The following options should be selected BEFORE pressing the Start Pause button. The light on each option button will come on if that option has been selected. Delay Start This option is available to delay the start of the wash cycle by up to 9 hours. The selection of the time is completed by pressing the Delay Start button, the countdown display will indicate the time selected. -
Page 19: Automatic Features
40005508.qxd 05/03/2008 11:06 Page 19 Automatic Features Automatic Variable Capacity (Half Load) The washing machine is fitted with a self adjusting water level system. This system enables the machine to use the optimum amount of water needed to wash and rinse the laundry in relation to the particular load. -
Page 20: Programme Selector
40005508.qxd 05/03/2008 09:50 Page 20 Programme Selector For handling the various types of fabric and their level of soiling in your laundry the washing machine has different programme groups according to type of wash, temperature, spin speeds and duration (see Programme Guide). Cottons The Cottons programmes are designed for maximum washing and rinsing. -
Page 21: Daily Programmes
40005508.qxd 05/03/2008 09:50 Page 21 out using a high water level to provide the best results. The programme has a maximum temperature of 30°C and concludes with 3 rinses, one for fabric conditioner, and a short spin at 800rpm. Silk This washing machine also has a gentle Silk and Hand Wash programme. -
Page 22: Programme Guide
40005508.qxd 05/03/2008 09:50 Page 22 Programme Guide Maximum Maximum Programme Fabric Type Load Water Size (kg) Temp (°C) Cottons (including Cottons, linens Prewash) Colourfast Cotton, colourfast mixed fibres Non-fast Cottons, mixed fabrics, Coloureds Non-fast AA 40 Cottons, mixed fabrics and synthetics Synthetics Mixed fabrics (including... -
Page 23: A Typical Wash
40005508.qxd 05/03/2008 09:50 Page 23 A Typical Wash This section summarises the main points when completing a wash cycle. For detailed explanations of features, options and details of the machine refer to the relevant section in the instruction manual. Preparing the laundry Select and sort the laundry according to the wash care labels found on each garment. -
Page 24: Selecting The Wash Programme
40005508.qxd 05/03/2008 09:51 Page 24 Selecting the wash programme Refer to the Programme Guide or the programme descriptions on the front of the machine to select the most suitable programme. The programme is selected by turning the programme selector and aligning the programme name with the indicator. Check that the STOP indicator is flashing, if not check that the door is properly closed. -
Page 25: Cleaning And Routine Maintenance
40005508.qxd 05/03/2008 09:51 Page 25 Cleaning and Routine Maintenance The washing machine needs very little maintenance, but regular attention to a few small details will ensure the continued performance of your washing machine. Do not use abrasive cleaners, scouring pads, solvent based cleaners or polishes;... -
Page 26: Cleaning The Filter
40005508.qxd 05/03/2008 09:51 Page 26 Cleaning the filter The washing machine is fitted with a special filter to prevent items such as coins, buttons, etc. blocking the discharge hose. These may be retrieved by: Removing the kickplate by gently pulling it from the bottom in an outwards and upwards direction. -
Page 27: Troubleshooting
40005508.qxd 05/03/2008 09:51 Page 27 Troubleshooting What might be the cause of... Defects you can remedy yourself Before calling GIAS Service for technical advice please run through the following checklist. A charge will be made if the machine is found to be working or has been installed incorrectly or used incorrectly. -
Page 28: The Door Will Not Open
40005508.qxd 05/03/2008 09:51 Page 28 Water on the floor around the washing machine…. ● Is the fill hose tightened? If so, replace the rubber washers and re-tighten. ● Is the standpipe or the household drain blocked? If so, clear the blockage yourself or call a plumber. ●... - Page 29 40005508.qxd 05/03/2008 09:51 Page 29 ● Has the programme finished but the door remains locked? The START and TIME SAVER light will flash intermittently indicating that the water supply has been interrupted during the wash cycle. Turn the machine to OFF to reset the machine and this will allow the door to open.
-
Page 30: Power Failure
40005508.qxd 05/03/2008 09:51 Page 30 Power Failure If there is a power failure the wash cycle will be interrupted, and the wash programme and functions will be suspended. When the power is restored, the wash programme and functions will re-start from the same point and complete the programme. -
Page 31: Customer Service
For a period of one year from the date of purchase the appliance is covered by a guarantee which allows you to call Hoover Service free of charge (except for the price of the call). Phone GIAS on 08705 400 600 Remember to send off the guarantee certificate for validation within 10 days of the date of purchase. -
Page 32: Your Guarantee
09:51 Page 32 Your Guarantee Hoover guarantees all parts of this product for 5 years from the date of purchase. During that time Hoover will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear such as belts. The call out fee and labour costs are chargeable after the first 12 months.
