through 16. If this field is left blank, the camera will not respond. In the example above, Camera 1 will
go to Preset 1, while Camera 2 will go to Preset 9.
Relay: Configure which relay will be triggered when an alarm is activated per camera. Select from:
1
2
Intrusion AND/OR: Use this feature to activate alarms by hardwired alarm inputs AND/OR Intrusion
detection. Select from AND or OR. Motion Detection must be set to Intrusion and linked to the Alarm
number.
Rotate the Jog to navigate and the Shuttle to change the values.
q Main Menu
Use this menu to determine how the unit will record cameras in alarm.
No Change: Unit changes to the Alarm Record Rate, but it does not
give priority to the camera in alarm.
Exclusive: The unit records only the camera (or cameras) in alarm.
Interleaved: Alarmed cameras are recorded at a higher rate than
non-alarm cameras. The unit accomplishes this by interleaving images
of alarmed cameras between images from non-alarmed cameras in the record list. Interleaved is the
recommended mode of operation.
Example of Record Lists:
No Change record list for 8 cameras, Camera-4 in alarm.
Exclusive record list for 8 cameras, Camera-4 in alarm.
Interleaved record list for 8 cameras, Camera-4 in alarm.
q Main Menu
Use this menu to Enable or Disable the alarm inputs.
Select from the following:
Individual Enable: Allow the user to access the Alarm
Enable submenu, and enable or disable alarm inputs on
a per camera basis.
Enable All
Disable All
Rotate the Jog to navigate, and the Shuttle to change
the values.
Save changes and exit the menu: Select [OK], then press the
Enter button.
Exit the menu without making changes: Press the Menu
button, or select [CANCEL], then press the Enter button.
0150-0239D
Alarms Alarm Record Mode
Alarms Enable / Disable
1 + 2
None
1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
4 4 4 4 4 4 4 4 4 4 4 4 4 4 4 4
1 4 2 4 3 4 5 4 6 4 7 4 8 4 1 4
41
Alarm Record Mode
Select Mode
Interleaved
Individual Enable
Enable All
Disable All
