- Page 1 User's Manual FST-801 FST-802 FST-802S15/802S35/802S50 FST-806A20/806B20 10/100Base-TX to 100Base-FX Smart Media Converter - 1 -...
-
Page 2: Fcc Warning
Trademarks Copyright © PLANET Technology Corp. 2010 Contents subject to revision without prior notice. PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose. -
Page 3: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION ..............................4 1.1 C ................................4 HECKLIST 1.2 A 10/100B 100B -FX S ............. 4 BOUT THE MART EDIA ONVERTER 1.3 F ................................. 4 EATURES 1.4 S ................................5 PECIFICATION 1.5 P ..............................6 RODUCT UTLOOK 2. -
Page 4: Introduction
1. INTRODUCTION 1.1 Checklist Thank you for purchasing PLANET 10/100Base-TX to 100Base-FX Smart Media Converter, the 10/100Base-TX to 100Base-FX Smart Media Converter package shall contain following contents: Check the contents of your package for following parts: 10/100Base-TX to 100Base-FX Smart Media Converter x1 User's manual CD x1 DC 5V 2A Power Adapter x1 If any of these pieces are missing or damaged, please contact your dealer immediately, if possible, retain the carton... -
Page 5: Specification
1.4 Specification Model FST-801 FST-802 FST-802S15 FST-802S35 FST-802S50 FST-806A20 FST-806B20 Hardware Specification Standards IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX and 100Base-FX Ports 1 10/100Base-TX port , 1 100Base-FX port Fiber connector SC, WDM SC, WDM Wavelength 1310nm (Transmit and Receive) -
Page 6: Product Outlook
1.5 Product Outlook Right View: there is one RJ-45 twisted-Pair jack (Auto-MDI/MDI-X), one fiber-optic connector (vary by model) and six LED indicators. Left View: there is one DC jack for DC 5V power adapter. 10/100Base-TX FDX Fast Ethernet Bridge 10/100Base-TX to 100Base-FX 100Base-FX LED Indicators Color... -
Page 7: Hardware Installation
2. HARDWARE INSTALLATION This product provides two different running speeds – 10/100Base-TX and 100Base-FX in the same device and the 10/100Base-TX RJ-45 port can automatically distinguish the speed of incoming connection. This section describes the hardware installation of FST-80x. Before connecting any network device to the FST-80x, read this chapter carefully. -
Page 8: Slide Media Converter Module Into Mc-1600Mr/R48 Chassis Installation
2.2 Slide Media Converter module into MC-1600MR/R48 Chassis installation Step 1- Unscrew and pull out the FST-80x Media Converter board. Step 2- Remove a blank faceplate from an empty expansion slot on the front of the chassis. The FST-80x Media Converter board can be installed in any expansion slot. -
Page 9: Real Ethernet Environment Application
2.3 Real Ethernet environment application Standalone and centralize management Media Converter installation Afford the current network grows and expanding, the PLANET FST-80x provide advanced Media conversion technology to fill this kind of demand. The FST-80x provide the diverse fiber connect type options to meet different network application, it is very flexible for FST-80x work as a standalone devices or install into the central Web Smart Media converter chassis for centralize management. -
Page 10: Manage The Media Converter
3. MANAGE THE MEDIA CONVERTER This product provides two different managed methods – configure through its DIP Switch or install into the central Web Smart Media converter chassis for centralize management. This section describes how to managed the FST-80x through its DIP Switch and Web Smart Media converter chassis. Before use the FST-80x smart function, please read this chapter carefully. -
Page 11: Managed Media Converter Module Through Mc-1600Mr/R48 Chassis
3.2 Managed Media Converter module through MC-1600MR/R48 Chassis The Web Smart Media Coverter Chassis that can control FST-80X through the management system,FST-80X can be controlled through Web Browser and terminal emulation program. The Web Smart Media Converter Chassis will display out the status of FST-80x, also the Web Smart Media Coverter Chassis can control the function through the management system. -
Page 12: Link Pass Through Function
4. LINK PASS THROUGH FUNCTION The LFP function includes the Link Fault Pass Through function (LLCF/LLR) and the DIP Switch design. LLCF/LLR can immediately alarm administrators the problem of the link media and provide efficient solution to monitor the net. The DIP Switch provides disable or enable the LFP function. -
Page 13: Link Loss Return (Llr)
4.2 Link Loss Return (LLR) The fiber ports of FST-80X have been designed with an LLR function for troubleshooting a remote connection. LLR works in conjunction with LLCF. When LLR is enabled*, the port’s transmitter shuts down when its receiver fails to detect a valid receive link. LLR should only be enabled on one end of the link and is typically enabled on either the unmanaged or remote device. -
Page 14: Troubleshooting
5. TROUBLESHOOTING This chapter contains information to help you solve issues. If the FST-80x is not functioning properly, make sure the FST-80x was set up according to instructions in this manual. The Power LED is not lit Solution: Check the power cable connection between power adapter and FST-80X. Why I connect FST-80x to device with 100Base-FX interface and the 100Base-FX fiber connection fail? Solution: Please check the fiber connection between two devices is correct. -
Page 15: Appendix A Networking Connection
APPENDIX A NETWORKING CONNECTION A.1 Switch‘s RJ-45 Pin Assignments 10/100Mbps, 10/100Base-TX RJ-45 Connector pin assignment Contact MDI-X Media Dependant Media Dependant Interface Interface -Cross Tx + (transmit) Rx + (receive) Tx - (transmit) Rx - (receive) Rx + (receive) Tx + (transmit) 4, 5 Not used Rx - (receive) -
Page 16: Cable Connection Parameter
A.3 Cable Connection Parameter The limitations are shown as below; Duplex Connection Limitation (max.) Twisted Pair Half / Full Node to Node 100 meters Node to Switch/ Hub Multi-Mode Converters MM Half Node to Node 412 meters Node to Switch MM Full Node to Node 2 kilometers... -
Page 17: Ec Declaration Of Conformity
: FST-806A20/B20 * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address : 11F, No. 96, Min Chuan Road, Hsin Tien Taipei, Taiwan , R. O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC). - Page 18 : FST-802S15_S35_S50 * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address : 11F, No. 96, Min Chuan Road, Hsin Tien Taipei, Taiwan , R. O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC).
- Page 19 : FST-801_802 * Produced by: Manufacturer‘s Name : Planet Technology Corp. Manufacturer‘s Address : 11F, No. 96, Min Chuan Road, Hsin Tien Taipei, Taiwan , R. O.C. is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility Directive on (89/336/EEC).
