Trademarks
Copyright
PLANET Technology Corp. 2002.
Contents subject to revision without prior notice.
PLANET is a registered trademark of PLANET Technology
Corp. The information in this manual is subject to change
without notice. All other trademarks belong to their respective
owners.
Disclaimer
PLANET Technology does not warrant that the hardware will
work properly in all environments and applications, and
makes no warranty and representation, either implied or ex-
pressed, with respect to the quality, performance, mer-
chantability, or fitness for a particular purpose.
PLANET has made every effort to ensure that this User's
Manual is accurate; PLANET disclaims liability for any inac-
curacies or omissions that may have occurred. Information in
this User's Manual is subject to change without notice and
does not represent a commitment on the part of PLANET.
PLANET assumes no responsibility for any inaccuracies that
may be contained in this User's Manual. PLANET makes no
commitment to update or keep current the information in this
User's Manual, and reserves the right to make improvements
to this User's Manual and/or to the products described in this
User's Manual, at any time without notice. If you find infor-
mation in this manual that is incorrect, misleading, or incom-
plete, we would appreciate your comments and suggestions.
FCC Warning
This equipment has been tested and found to comply with the
regulations for a Class A digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference when the
equipment is operated in a commercial environment. This

Advertisement

Table of Contents
loading

Summary of Contents for Planet FT-701B

  • Page 1 All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or ex- pressed, with respect to the quality, performance, mer- chantability, or fitness for a particular purpose.
  • Page 2 Revision User's manual for PLANET Fast Ethernet Converter Multi-mode: FT-701B, FT-702B, FT-703, FT-704, FT-705 Single-mode: FT-702S15, FT-702S35, FT-702S50, FT-703S, FT-706A15, FT-706B15 Rev 3.0 (Oct. 2002)
  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 OVERVIEW ..........1 CHAPTER 2 MODEL LIST ..........1 CHAPTER 3 CHECKLIST ..........2 CHAPTER 4 PRODUCT OUTLOOK......2 CHAPTER 5 INSTALLING THE CONVERTER ..... 3 CHAPTER 6 DUPLEX MODE SETTING ....... 4 CHAPTER 7 THE LED INDICATIONS......5 CHAPTER 8 CABLE CONNECTION PARAMETER ..
  • Page 4: Chapter 1 Overview

    Please contact with your sales representative for more about the 19” media chassis. Chapter 2 MODEL LIST Your Fast Ethernet Converter comes with one of the following models. ð FT-701B on board ST fiber connector ð FT-702B/S on board SC fiber connector ð FT-703/S on board MT-RJ fiber connector ð...
  • Page 5: Chapter 3 Checklist

    Chapter 3 CHECKLIST Your FT-70X carton should contain the following items: ð The Fast Ethernet Converter ð AC-DC Power Adapter (Output: 5VDC, 2 A max.) ð This user’s manual If any item is missing or damaged, please consult the dealer from whom you purchased your Fast Ethernet Converter.
  • Page 6: Chapter 5 Installing The Converter

    Side View (FT-70X) One DIP Switch for TP Device selection. Chapter 5 INSTALLING THE CONVERTER Please follow these steps to install the converter: Turn off the power of the device/station in a network to which the FT-70X will be attached. Ensure that there is no activity in the network.
  • Page 7: Chapter 6 Duplex Mode Setting

    Note: n RJ-45/STP, UTP Cat 5, straight-through cable is ac- cepted. n Cabling from FT-70X TP port to a TP device is as below: To Workstation: DIP switch on DTE To Hub/Switch: DIP switch on MPR Please refer to section 8 for more about the wiring dis- tance of your TP, Optic-fiber networks.
  • Page 8: Chapter 7 The Led Indications

    Chapter 7 THE LED INDICATIONS COLOR Status DESCRIPTION If fiber-optic is not present for converter self Blinks -diagnose / detecting If both ports link with any TP packets Blinks transmitting TP ACT Green Fiber-optic link is present With no TP/FX LINK on, i.e. only turn on the power and the ACT do not blink at all, pleas consult your local dealer TP Link Green...
  • Page 9: Chapter 8 Cable Connection Parameter

    Chapter 8 CABLE CONNECTION PARAMETER The cable distance limitations are as below: Duplex Connection Limitation (max.) Twisted Pair Node to Node Half / Full 100 meters Node to Switch/Hub Multi-Mode Converters Node to Node MM Half* 412 meters Node to Switch Node to Node MM Full 2 kilometers...
  • Page 10: Chapter 9 Technical Specifications

    Chapter 9 TECHNICAL SPECIFICATIONS The FT-70X comes with the following features: Standard IEEE 802.3u, 100Base-TX and 100Base-FX TP Connector One RJ-45 Twisted Pair, EIA568 connectors FT-701B: ST FT-702B: SC FT-702S series: SC Fiber Connector FT-703 series: MT-RJ FT-704 series: VF-45...
  • Page 11 Part No.:2010-000001-002...
