Using the MX500
Editing From the Program Display
1. While on the Program Screen, turn the Page/Select knob to highlight the effect
2. Turn Edit Knob A, B, or C to modify a parameter setting.
When finished, store the changes to the program if you would like them to be recalled.
From the Program Edit Menus
1. While on the Program Screen, turn the Page/Select knob to highlight the effect
2. Press the Page/Select knob. This will enter the Program Edit menus.
3. Once in the Program Edit menu, there can be two effects to edit, Effect 1 and Effect
4. Press the Page/Select knob to enter the Edit Effect menu.
5. Turn the Page/Select knob until the parameter(s) you want to edit appear in
6. Turn Edit Knob A, B, or C associated with the parameter you would like to edit
When finished, store the changes to the program if you would like them to be recalled.

changIng an effect

Each program offers a library of effects that can be used in the available effect mod-
ules. This allows you to customize a preset with the effects you need for your particular
application.
1. While on the Program Screen, press the Page/Select knob. This will enter the
2. Turn the Page/Select knob until the Change Effect menu is highlighted.
3. Press the Page/Select knob to enter the Change Effect 2 menu.
4. Once in the change effect menu, turn the Page/Select knob to move through
5. Press the Page/Select knob to load the newly selected effect into the effect loca-
you want to edit.
you want to edit.
2. Turn the Page/Select knob until the effect you want to edit is highlighted
(Edit Effect 1 menu is highlighted in our example).
the Main Display. Each parameter has either an A, B, or C labeled to the left of
its name indicating which Edit Knob will modify its value.
to change its setting.
Program Edit menus.
Change Effect 2 is selected in our example.
the library of effects until you find the one you want to use. If you choose not to
select a new effect, press the Exit button to abort changing effects.
tion. You will be able to hear the new effect in place in the effect routing at this
time.
