D General
• Frequency coverage
Version TX
U.S.A.
144–148
AUS
CHN
136–174*
EXP
EUR
UK 144–146
KOR
• Mode
• Number of memory channels
• Usable temperature range
• Tuning steps
• Frequency stability
• Power supply
• Current drain
(at 7.2 V DC: typical)
Transmit at 5.5 W (High)
at 2.5 W (Mid.)
at 0.5 W (Low)
Receive standby
power save
max. audio
• Antenna connector
:
(unit: MHz)
RX
136–174*
136–174*
144–146
* Guaranteed: Only 144–148 MHz range
: FM, FM-N
: 207
(incl. 6 scan edges and 1 Call channel)
: –20°C to +60°C; –4°F to +140°F
: 5, 10, 12.5, 15, 20, 25, 30 and
50 kHz
: ±2.5 ppm
(–20°C to +60°C; –4°F to +140°F)
: Icom specified battery pack/case
: 1.4 A
0.9 A
0.6 A
: 65 mA
20 mA
310 mA (internal speaker)
180mA (external speaker)
: BNC (50 W)

SPECIFICATIONS

• Dimensions
(projections not included)
• Weight
(approx.)
(without battery pack/case and ant.)
D Transmitter
• Modulation system : Variable reactance freq. modulation
• Output power : High 5.5 W, Mid. 2.5 W, Low 0.5 W.
(at 7.2 V DC)
• Max. frequency deviation : FM
• Spurious emissions : Less than –60 dBc
• External mic. connector : 3-conductor 2.5 (d) mm (
D Receiver
• Receive system : Double-conversion superheterodyne
• Intermediate frequencies : 1st: 21.7 MHz, 2nd: 450 kHz
• Sensitivity : –0.14 μV typ.
(at 12 dB SINAD)
• Squelch sensitivity : –0.1 μV typ.
(threshold)
• Selectivity : FM
• Spurious and image rejection : 75 dB typ.
• Intermodulation : FM
• Audio output power (at 10% distortion)
Internal speaker : 0.75 W typ. with a 16 Ω load
: 0.45 W typ. with a 8 Ω load
External speaker
• External speaker connector : 3-conductor 3.5(d) mm; (
All stated specifications are subject to change without notice or
obligation.
15
: 58(W)×112(H)×30(D) mm;
2 9 ⁄ (W)×4 13 ⁄ (H)×1 3 ⁄ (D) in
32 32 16
: 140 g; 4.9 oz
±5.0 kHz
(wide)
FM ±2.5 kHz
(narrow)
1 ⁄ ˝)/2.2 kΩ
10
70 dB typ.
(wide)
FM 50 dB typ.
(narrow)
70 dB typ.
(wide)
FM 65 dB typ.
(narrow)
1 ˝)/8 Ω
⁄
