BATTERY CHARGING

■ Battery chargers

D Using the BC-191 to rapid charge the BP-264
The BC-191 provides rapid charging of only the BP-264 Ni-MH
battery pack. Never use it to charge any other battery pack.
Charging time: Approx. 2 hours
The following item is additionally required:
• An AC adapter (not supplied with some versions) or the OPC-515L
or CP-23L DC power cable.
AC adapter
(A different type, or no AC
adapter is supplied, de-
pending on the version.)
The optional OPC-
515L (for DC power
source) or CP-23L
(for 12 V cigarette
lighter socket) can
be used instead of
the AC adapter.
11
Battery pack Transceiver
Turn power OFF
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
*Purchase separately.
Using screws
recommended
secure the charger.
Charge indicator
• Lights orange : While charging
• Lights green : Charging is completed.
D Using the BC-192 to regular charge the BP-264
The BC-192 provides regular charging of only the BP-264
Ni-MH battery pack. Never use it to charge any other battery
pack.
Charging time (with the 147S): Approx. 16 hours
The following item is additionally required:
• An AC adapter (not supplied with some versions) or the OPC-515L
DC power cable.
AC adapter
(A different type, or no AC
adapter is supplied, de-
pending on the version.)
The optional OPC-
515L (for DC power
is
source) can be
to
used instead of the
AC adapter.
Charging time period differs
depending on the input voltage.
12 V : Approx. 36 hours
13.8 V : Approx. 21 hours
16 V : Approx. 16 hours
Battery pack Transceiver
Turn power OFF
Screws*
(Self tapping screw:
M3.5 × at least 30 mm)
*Purchase separately.
Using screws
recommended
secure the charger.
Charge indicator
• Lights green while charging.
NOTE:
The charge indicator will not
go out even after a battery
pack is fully charged.
