BIIS OPERATION
I Position data transmission
When the optional OPC-966
is connected to the transceiver, the position (longitude and latitude)
data can be transmitted automatically.
Ask your dealer or system operator for connection details.
The position data is transmitted when;
• Status 24 message is received
*When the status 24 message, GPS request, is received.
• Fully automatic
When automatic position transmission is enabled, send the po-
sition data according to 'Time Marker' and 'Interval Timer' set-
tings.
• PTT is released
When 'Send with Logoff' is enabled.
- Set the "Log-In/Off" item as "L-OFF".
• After sending a status message
When 'Send with Status' is enabled.
• After sending an SDM
When 'Send with SDM' is enabled.
• After sending status 22 (Emergency)
When 'Send with Emergency' is enabled.
31
INTERFACE CABLE
and a GPS receiver
