6
BATTERY CHARGING

■ Optional battery chargers

D Rapid charging with the BC-160
The optional BC-160 provides rapid charging of optional Li-
Ion battery packs.
• An AC adapter (may be supplied with BC-160 depending
on version) or the DC power cable (OPC-515L/CP-17L) is
additionally required.
AC adapter
(Not supplied with
some versions.)
Optional OPC-
515L (for 13.8 V
power source) or
CP-17L (for 12 V
cigarette lighter
socket) can be
used instead of
the AC adapter.
20
Turn power OFF
Battery
pack
Transceiver
D AD-106 installation
The AD-106
charger adapter
BC-119N or BC-121N before battery charging.
➥ Connect the AD-106
charger adapter
119N/BC-121N as below, then install the AD-106 into the
holder space of the BC-119N or BC-121N with the sup-
plied screws.
AD-106
Plugs
* This illustration is described with BC-119N.
must be installed into the
and the BC-
Connectors
Screws supplied
with the charger
adapter
