I Optional Battery Chargers - Icom IC-M88 Instruction Manual

9
BATTERY CHARGING

I Optional battery chargers

D Rapid charging with the BC-119N+AD-100
The optional BC-119N provides rapid charging of battery
packs. The following are additionally required.
• AD-100
• An AC adapter (may be supplied with BC-119N depending
on version).
AC adapter
(Not supplied with
some versions.)
OPC-515L or
CP-17L
An optional cable OPC-515L
(for 13.8 V power source) or
CP-17L (for 12 V cigarette
lighter socket) can be used
in-stead of the AC adapter.
22
IC-M88
BP-227
AD-100 charger
adapter is instal-
led in BC-119N.
D Rapid charging with the BC-121N+AD-100
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following are additionally re-
quired.
• Six AD-100.
• An AC adapter (BC-124) or the DC power cable (OPC-656).
IC-M88
BP-227
AC adapter
(purchased
separately)
DC power cable
(Connect with the DC power supply;
13.8 V/at least 7 A)
AD-100 charger
adapters are installed
in each slot.
