Invacare® Veranda™Wheelchair
User Manual
This manual MUST be given to the user of the product.
BEFORE using this product, read this manual and save for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Invacare Veranda

Summary of Contents for Invacare Veranda

  • Page 1 Invacare® Veranda™Wheelchair User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
  • Page 2 © 2010 Invacare Corporation. All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.

  • Page 3: Table Of Contents

    A Note to Wheelchair Assistants........................................16 Tipping ..................................................16 Stairways ................................................17 Escalators ................................................19 Transferring To and From Other Seats......................................19 Unfolding and Folding Wheelchair........................................20 SAFETY INSPECTION/TROUBLESHOOTING Safety Inspection Checklist ..........................................23 Troubleshooting .......................................26 Maintenance ................................................26 Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 4 Changing Seat-to-Floor Height ......................................... 33 10 REAR WHEELS 11 FRONT CASTERS/FORKS Removing/Installing Eight Inch Forks ....................................... 36 Adjusting Forks..............................................36 Removing/Installing Front Casters ........................................37 12 ANTI-TIPPERS/WHEEL LOCKS Installing/Adjusting Anti-tippers........................................38 Using/Adjusting The Wheel Locks........................................40 Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 5: General

    Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided.  Gives useful tips, recommendations and information for efficient, trouble-free use. Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 6: Limited Warranty

    This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare warrants this product to be free from defects in materials and workmanship for a period of one year from date of purchase. If within such warranty period any such product shall be proven to be defective, such product shall be repaired or replaced, at Invacare’s option.

  • Page 7: Overview

    1/8" when handle is engaged to the lock position (3/16" for pneumatic tires). Tube Tighten mounting fastener to secure mounting bracket in desired location and recheck lock shoe embedding. Inspect for correct locking action BEFORE actual use. 00078X021-0394 Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 8: Typical Product Parameters

    REAR AXLE: Dual Axle REAR WHEELS: 24-inch composite wheel/solid rubber tire HANDRIMS: Composite WHEEL LOCKS: Push to lock CASTER SIZE: 8x1-inch solid rubber UPHOLSTERY: Black nylon FRAME FINISH Black Invacare® Veranda™Wheelchair Part No. 1148116...
  • Page 9 24.10 kg 43.5 47.3 45.1 41.2 24.40 kg 22.75 kg (APPROX.): pounds pounds pounds pounds WEIGHT LIMITATION: 250 lbs (114 kg)  These heights can vary ± ¼ inch due to tire wear and manufacturing tolerances. Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 10: Safety

    NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. Check all parts for shipping damage and test before using. In case of damage, DO NOT use. Contact Invacare/Carrier for further instruction. Invacare® Veranda™Wheelchair Part No. 1148116...
  • Page 11 Wheelchair User As a manufacturer of wheelchairs, Invacare endeavors to supply a wide variety of wheelchairs to meet many needs of the end user. However, final selection of the type of wheelchair to be used by an individual rests solely with the user and his/her healthcare professional capable of making such a selection.

  • Page 12: Operating Information

    Anti-tippers MUST be fully engaged and release buttons fully protruding out of adjustment holes. Anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (you may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as an additional safeguard for the wheelchair user.

  • Page 13: Weight Training

    Invacare does not recommend the use of its wheelchairs as a weight training apparatus. Invacare wheelchairs have not been designed or tested as a seat for any kind of weight training. If occupant uses said wheelchair as a weight training apparatus, Invacare shall not be liable for bodily injury or damage to the wheelchair and the warranty is void.

  • Page 14: Safety/Handling Of Wheelchairs

    Use this information only as a basic guide. The techniques that are discussed on the following pages have been used successfully by many. Individual wheelchair users often develop skills to deal with daily living activities that may differ from those described in this manual. Invacare recognizes and encourages each individual to try what works best for him/her in overcoming architectural obstacles that they may encounter.
  • Page 15 Virtually all activities which involve movement in the wheelchair have an effect on the center of gravity. Invacare recommends using seat/chest positioning straps for additional safety while involved in activities that shift your weight.

  • Page 16: Coping With Everyday Obstacles

    When tipping the wheelchair, an assistant should grasp the back of the wheelchair on a non-removable (non-detachable) part. Inform the wheelchair occupant before tipping the wheelchair and remind him/her to lean back. Be sure the occupant’s feet and hands are clear of all wheels and/or pinch points. Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 17: Stairways

    Extreme caution is advised when it is necessary to move an occupied or unoccupied wheelchair up or down the stairs. Invacare recommends that, if possible, the user be removed from the wheelchair prior to moving. Invacare recommends using two assistants and making thorough preparations. Make sure to use only secure, non-detachable parts for hand-held supports.
  • Page 18 The wheelchair should not be lowered until the last stair has been FIGURE 4 Unfolding and Folding Wheelchair negotiated and the wheelchair has been rolled away from the stairway. If necessary, rotate the anti-tippers so the wheels are facing down. Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 19: Escalators

    Shift body weight into seat with transfer. During independent transfer, little or no seat platform will be beneath you. Use a transfer board if at all possible. FIGURE 5 Unfolding and Folding Wheelchair Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 20: Unfolding And Folding Wheelchair

    Press downward on the top of the seat rail until the wheelchair is fully open and the seat rails are in lowest position. Engage both wheel locks, refer to Using The Wheel Locks on page 40. Open the footrest/legrest for clearance and transfer into the wheelchair. Refer to Transferring To and From Other Seats on page 19. Invacare® Veranda™Wheelchair Part No. 1148116...
  • Page 21 With both hands, grasp the middle of the seat upholstery at the front and back edge and lift up. CAUTION DO NOT allow upholstery to hang between the cross braces. Place excess seat upholstery over the armrest. Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 22 4 SAFETY/HANDLING OF WHEELCHAIRS FIGURE 7 Folding Wheelchair Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 23: Safety Inspection/Troubleshooting

    ❑ Inspect the back cane hand grips for wear/looseness/deterioration. ❑ Inspect tires for flat spots and wear. CAUTION As with any vehicle, check the wheels and tires periodically for cracks and wear. Replace if damaged. Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 24 ❑ Inspect front caster for cracked, bent or broken spokes. ❑ Ensure the casters are free of debris. Inspect/Adjust Monthly ❑ Ensure that the wheelchair rolls straight (no excessive drag or pull to one side). Invacare® Veranda™Wheelchair Part No. 1148116...
  • Page 25 ❑ Inspect casters for cracks and wear (hub and rim). ❑ Clean upholstery and armrests. ❑ Check that all labels are present and legible. Replace if necessary. ❑ Ensure the casters are free of debris. Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 26: Troubleshooting

    DO NOT overtighten hardware attaching to the frame. This could cause damage to the frame tubing. Suggested Maintenance Procedures Before using your wheelchair, make sure all nuts and bolts are tight. Check all parts for damage or wear and replace. Check all parts for proper adjustment. Invacare® Veranda™Wheelchair Part No. 1148116...
  • Page 27 Hand grips should be checked monthly for wear/looseness/deterioration. Clean if desired. Replace if looseness or deterioration is found. Check upholstery for sagging, rips or tears. Replacing/Repairing Rear Wheel Tire/Tube WARNING Replacement of solid rubber tires is not recommended. If the solid rubber tire needs repaired, Invacare recommends replacing the complete wheel assembly. Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 28 5 SAFETY INSPECTION/TROUBLESHOOTING Replacing/Repairing Caster Tire/Tube WARNING Replacement of solid rubber tires is not recommended. If the solid rubber tires need replaced, Invacare recommends replacing complete caster assembly. Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 29: Front Rigging

    Push the release lever inward and rotate the front rigging outward. Hinge Plates Lift up on front rigging and remove from the wheelchair. Footplate Repeat STEPS 1-2 for the opposite side of the wheelchair. FIGURE 1 Installing/Removing Front Riggings Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 30: Adjusting Footrest Height

    To lower the elevating legrest, perform the following: Support Tube Support the user leg with one hand. Push legrest release lever down with other hand. Gently lower user leg down and rest it against the legrest. FIGURE 3 Raising/Lowering Elevating Legrest Assembly Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 31: Arms

    Push the armrest down and evenly at both ends until the front release button snaps into arm socket hole. Arm Socket Arm Socket Repeat STEPS 1 and 2 for the other armrest. FIGURE 1 Removing/Installing Armrests (Removable Armrests Only) Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 32: Back

    Secure the back cane to the wheelchair frame with the hex screw and locknut. Secure the new back upholstery to the back canes with the existing mounting screws and washers. Mounting Screw Back Cane FIGURE 1 Replacing Standard Back Upholstery Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 33: Seat To Floor

    Reinstall the rear wheels onto the wheelchair in the mounting position indicated in the chart. Refer to Removing/Installing Rear Wheels on page 35. Adjust anti-tippers according to new seat-to-floor height. Refer to Installing/Adjusting Anti-tippers on page 38. Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 34 24 inch Bottom mounting hole on frame DETAIL “A” - REAR WHEEL DETAIL “B” - 8 INCH MOUNTING POSITIONS- CASTER MOUNTING ADULT/HEMI FRAME STYLE POSITIONS Middle Hole not used Bottom Bottom FIGURE 1 Changing Seat-to-Floor Height Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 35: Rear Wheels

    To reinstall the rear wheel(s) onto the wheelchair, reverse STEPS 1-2. Torque the locknut to 40 ft-lbs. Adjust the wheel locks. Refer to Adjusting the Anti-Tippers. on page 39. Dust Spacer Wheelchair Frame Hex Screw FIGURE 1 Removing/Installing Rear Wheels Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 36: Front Casters/Forks

    A. Tip back of wheelchair to floor. Pivot both forks and casters to top of their arc simultaneously. Let casters drop to bottom of arc (wheels should swing once to one-side, then IMMEDIATELY rest in a straight downward position). Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 37: Removing/Installing Front Casters

    For Desired Seat To Floor Height on page 34. Secure the front caster to the fork in the mounting position Front determined in STEP 1 with hex screw, washers and locknut. Tighten Caster securely. FIGURE 2 Removing/Installing Front Casters Part No. 1148116 Invacare® Veranda™Wheelchair...

  • Page 38: Anti-Tippers/Wheel Locks

    If so equipped, anti-tippers MUST be attached at all times. Inasmuch as the anti-tippers are an option on this wheelchair (You may order with or without the anti-tippers), Invacare strongly recommends ordering the anti-tippers as a safeguard for the wheelchair user.
  • Page 39 2 inches. If the 1 to 2 inch distance cannot be achieved with the to 2 inch Clearance anti-tippers, a different model may be required. Contact an Invacare dealer or qualified technician. FIGURE 2 Adjusting the Anti-Tippers. Part No. 1148116...

  • Page 40: Using/Adjusting The Wheel Locks

    Pull wheel lock handle toward the tire to disengage wheel lock Wheel Lock Handle Wheel Wheel Lock Tire Wheel Lock Tire Lock Handle FIGURE 3 Using The Wheel Locks Invacare® Veranda™Wheelchair Part No. 1148116...

  • Page 41: Adjusting Wheel Locks

    If the measurement of 1/8-inch cannot be achieved, remove the bolt and locknut that secure the wheel lock to the wheelchair frame and mount the wheel lock in one of two mounting positions. 10. Repeat STEPS 1-9 until the wheel lock holds the wheelchair. If the correct measurement still cannot be achieved, contact a qualified technician. Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 42 12 ANTI-TIPPERS/WHEEL LOCKS Bolt and Locknut Mounting 1/8-inch Positions Wheel Lock Handle Wheel Wheel Lock Wheel Lock Lock DETAIL “A” - Shoe Shoe WHEEL LOCK SHOE Rear Wheel Tire ENGAGEMENT Tire FIGURE 4 Adjusting the Anti-Tippers. Invacare® Veranda™Wheelchair Part No. 1148116...
  • Page 43 NOTES NOTES Part No. 1148116 Invacare® Veranda™Wheelchair...
  • Page 44 Invacare Corporation Canada One Invacare Way 570 Matheson Blvd E Elyria, Ohio USA Unit 8 44036-2125 Mississauga Ontario 800-333-6900 L4Z 4G4 Canada 800-668-5324 Part No. 1148116 Rev B - 9/10 www.invacare.com...
