13. Orient the Storage Latch (84) so that the decals
are facing away from the treadmill as shown.
Attach the lower end of the Storage Latch (84) to
the Base (74) with an M8 x 45mm Bolt (65), two
Latch Spacers (82), and an M8 Nut (68).
Attach the upper end of the Storage Latch (84)
with an M8 x 53mm Bolt (67) and an M8 Nut
(68).
Lower the Frame (38) (see HOW TO LOWER
THE TREADMILL FOR USE on page 20).
14. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill.
Note: Extra parts may be included. Keep the included hex keys in a secure place; one of the hex keys is used
to adjust the walking belt (see page 22).
13
68
38
Decals
74
13
67
84
68
82 65
