Pro-Form 515 Zlt Treadmill User Manual page 10

7. Position the Console Crossbar (61) between
the Left and Right Handrails (59, 64) with the
Console Ground Wire (47) positioned as shown.
Attach the Console Crossbar (61) to the Left and
Right Handrails (59, 64) with the four
5/16" x 3/4" Screws (5) that you removed in
step 6. Start all four Screws, and then tighten
them.
8. Insert the included tie (C) through the indicated
holes in the top and bottom of the Right Handrail
(64) as shown. Make sure that the Upright
Wire (63) has been secured to the side
shown, and then tighten the wire tie.
7
61
5
59
8
63
10
47
64
5
64
C
