Pro-Form 515 Zlt Treadmill User Manual

English manual
Hide thumbs Also See for 515 Zlt Treadmill:
Table of Contents

Advertisement

Quick Links

Model No. PETL59713.0
Serial No.
Write the serial number in the space
above for reference.
Serial Number
CUSTOMER SERVICE
UNITED KINGDOM
Call: 08457 089 009
From Ireland: 053 92 36102
Website: www.iconsupport.eu
E-mail: csuk@iconeurope.com
Write:
ICON Health & Fitness, Ltd.
c/o HI Group PLC
Express Way
CASTLEFORD
WF10 5QJ
UNITED KINGDOM
AUSTRALIA
Call: 1800 993 770
E-mail: australiacc@iconfitness.com
Write:
ICON Health & Fitness
PO Box 635
WINSTON HILLS NSW 2153
AUSTRALIA
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
Decal
USER'S MANUAL
www.iconeurope.com

Advertisement

Table of Contents
loading

Related Manuals for Pro-Form 515 Zlt Treadmill

Summary of Contents for Pro-Form 515 Zlt Treadmill

  • Page 1 Model No. PETL59713.0 Serial No. USER’S MANUAL Write the serial number in the space above for reference. Serial Number Decal CUSTOMER SERVICE UNITED KINGDOM Call: 08457 089 009 From Ireland: 053 92 36102 Website: www.iconsupport.eu E-mail: csuk@iconeurope.com Write: ICON Health & Fitness, Ltd. c/o HI Group PLC Express Way CASTLEFORD...

  • Page 2: Table Of Contents

    Apply the decal in the location shown. Note: The decal(s) may not be shown at actual size. 305284 PROFORM is a registered trademark of ICON IP, Inc.

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read all important precautions and instructions in this manual and all warnings on your treadmill before using your treadmill. ICON assumes no responsibility for personal injury or property damage sus- tained by or through the use of this product.
  • Page 4 DANGER: 21. Do not attempt to move the treadmill until Always unplug the power it is properly assembled. (See ASSEMBLY cord immediately after use, before clean- on page 7 and HOW TO FOLD AND MOVE ing the treadmill, and before performing the THE TREADMILL on page 20.) You must be maintenance and adjustment procedures able to safely lift 45 lbs.

  • Page 5: Before You Begin

    515 ZLT manual. To help us assist you, note the product model ® treadmill. The 515 ZLT treadmill provides an impressive number and serial number before contacting us. The selection of features designed to make your workouts model number and the location of the serial number at home more effective and enjoyable.

  • Page 6: Part Identification Chart

    PART IDENTIFICATION CHART Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw- ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity used for assembly.

  • Page 7: Assembly

    ASSEMBLY • Assembly requires two persons. • To identify small parts, see page 6. • Place all parts in a cleared area and remove the • Assembly requires the following tools: packing materials. Do not dispose of the packing the included hex keys materials until you finish all assembly steps.
  • Page 8 3. Locate the Upright Wire (63) bundled between the Base (74) and the Belly Pan (52). Route the Upright Wire into the Base and out of the indi- cated hole. Press a Base Cap (70) into each side of the Base (74) (only one side is shown).
  • Page 9 5. Hold the Right Upright (76) against the Base (74). Be careful not to pinch the Upright Wire (63). Insert a 3/8" x 3 1/4" Screw (2) with a 3/8" Star Washer (3) into the top hole in the Right Upright (76).
  • Page 10 7. Position the Console Crossbar (61) between the Left and Right Handrails (59, 64) with the Console Ground Wire (47) positioned as shown. Attach the Console Crossbar (61) to the Left and Right Handrails (59, 64) with the four 5/16" x 3/4" Screws (5) that you removed in step 6.
  • Page 11 9. With the help of a second person, hold the con- sole assembly near the Right Handrail (64). Console Assembly See the inset drawing. Connect the Upright Wire (63) to the console wire. The connectors should slide together easily and snap into place.
  • Page 12 11. Attach the two Console Clamps (83) to the con- sole assembly with four #8 x 1" Screws (7). Console Assembly 12. Raise the Frame (38) to the position shown. Have a second person hold the Frame during the next two assembly steps. Attach the Latch Crossbar (44) to the Frame (38) with two 1/4"...
  • Page 13 13. Orient the Storage Latch (84) so that the decals are facing away from the treadmill as shown. Attach the lower end of the Storage Latch (84) to the Base (74) with an M8 x 45mm Bolt (65), two Latch Spacers (82), and an M8 Nut (68). Attach the upper end of the Storage Latch (84) with an M8 x 53mm Bolt (67) and an M8 Nut (68).

  • Page 14: Operation And Adjustment

    OPERATION AND ADJUSTMENT HOW TO PLUG IN THE POWER CORD Follow the steps below to plug in the power cord. This product must be earthed. If it should malfunc- 1. Plug the indicated end of the power cord into the tion or break down, earthing provides a path of least socket on the treadmill.
  • Page 15 CONSOLE DIAGRAM Clip FEATURES OF THE CONSOLE To turn on the power, see page 16. To use the man- ual mode, see page 16. To use a preset workout, see page 18. To use the information mode, see The treadmill console offers an impressive array of features designed to make your workouts more effec- page 19.
  • Page 16 HOW TO TURN ON THE POWER HOW TO USE THE MANUAL MODE IMPORTANT: If the treadmill has been exposed to 1. Insert the key into the console. cold temperatures, allow it to warm to room tem- perature before you turn on the power. If you do See HOW TO TURN ON THE POWER at the left.
  • Page 17 5. Follow your progress with the displays. 6. Measure your heart rate if desired. The far left display— Before using the When you select the handgrip heart manual mode, the matrix rate monitor, re- will display a track that move the sheets represents 400 m (1/4 of plastic from the mile).
  • Page 18 HOW TO USE A PRESET WORKOUT segment of the workout. The height of the flashing segment indicates the speed setting for the current 1. Insert the key into the console. segment. At the end of each segment, a tone will sound and the next segment of the profile will begin See HOW TO TURN ON THE POWER on page 16.

  • Page 19: Information Mode

    THE INFORMATION MODE The console features a display demo mode, designed to be used if the treadmill is displayed in a store. While The console features an information mode that keeps the demo mode is turned on, the console will function track of the total distance that the walking belt has normally when you plug in the power cord, press the moved and the total number of hours that the treadmill...

  • Page 20: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL HOW TO MOVE THE TREADMILL To avoid damaging the treadmill, adjust the incline Before moving the treadmill, fold it as described at the to zero before you fold the treadmill. Then, remove left.

  • Page 21: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by follow- c. Remove the key from the console, and then ing the simple steps below. Find the symptom that reinsert it. applies, and follow the steps listed. If further assis- tance is needed, see the front cover of this manual. d.
  • Page 22 SYMPTOM: The walking belt slows when walked on SYMPTOM: The walking belt is not centered between the foot rails a. If an extension cord is needed, use only a 3-con- IMPORTANT: If the walking belt rubs against the ductor, 14-gauge (1 mm ) cord that is no longer foot rails, the walking belt may become damaged.

  • Page 23: Exercise Guidelines

    EXERCISE GUIDELINES Burning Fat—To burn fat effectively, you must exer- WARNING: cise at a low intensity level for a sustained period of Before beginning this time. During the first few minutes of exercise, your or any exercise program, consult your physi- body uses carbohydrate calories for energy.

  • Page 24: Part List

    PART LIST Model No. PETL59713.0 R0913A Key No. Qty. Description Key No. Qty. Description #8 x 1/2" Ground Screw Latch Crossbar 3/8" x 3 1/4" Screw Filter 3/8" Star Washer Right Rear Foot #8 x 3/4" Screw Console Ground Wire 5/16"...

  • Page 25: Exploded Drawing

    EXPLODED DRAWING A Model No. PETL59713.0 R0913A...
  • Page 26 EXPLODED DRAWING B Model No. PETL59713.0 R0913A...
  • Page 27 EXPLODED DRAWING C Model No. PETL59713.0 R0913A 16 75...

  • Page 28: Ordering Replacement Parts

    ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) • the name of the product (see the front cover of this manual) • t he key number and description of the replacement part(s) (see the PART LIST and the EXPLODED DRAWING near the end of this manual) RECYCLING INFORMATION This electronic product must not be disposed of in municipal waste.
