GPS RECEIVER
GP-320B

Advertisement

Table of Contents
loading

Related Manuals for Furuno GP-320B

Summary of Contents for Furuno GP-320B

  • Page 1 GPS RECEIVER GP-320B...
  • Page 3 SAFETY INSTRUCTIONS CAUTION Confirm that the power supply voltage is compatible with the voltage rating of the equipment. Connection to the wrong power supply can cause fire or damage the equipment. NOTICE No one navigation device should ever be solely relied upon for the navigation of a vessel.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS SYSTEM OVERVIEW... iii EQUIPMENT LISTS ... v 1. MOUNTING ... 1 2. WIRING ... 2 3. DEFAULT SETTINGS ... 6 4. TROUBLESHOOTING, BATTERY ... 7 SPECIFICATIONS... SP-1 PACKING LIST OUTLINE DRAWING Declaration of Conformity...

  • Page 5: System Overview

    SYSTEM OVERVIEW The GP-320B is a GPS receiver with WAAS (Wide Area Augmentation System) capability. WAAS, available in North America, is a provider in the worldwide SBAS (Satellite Based Augmentation System) navigation system. An SBAS provider furnishes GPS signal corrections to SBAS users, for even better position accuracy, typically better than three meters.
  • Page 6 NavNet Series Model 1722C Model 1833C Model 1722 Model 1933C Model 1732C Model 1943C Model 1732 Model 1833 Model 1742C Model 1933 Model 1742 Model 1943 Model 1752C Model 1953C Model 1752 GD-1900C Model 1762C GD-1700C Model 1762 GD-1700 Multi Display RD-30* Echo Sounder LS-6100 * = WAAS is inoperative.

  • Page 7: Equipment Lists

    EQUIPMENT LISTS Standard supply Name GPS Receiver GP-320B Optional equipment Name Cable Assembly MJ-A7SPF/SRMD-100 000-144-534 Mast Mounting Kit CP20-01111 Right Angle NO.13-QA330 Antenna Base L-angle Antenna NO.13-QA310 Base Handrail-mount NO.13-RC5160 Antenna Base Type Code No. Type Code No. 004-365-780 000-803-239...
  • Page 8 (This page intentionally left blank.)

  • Page 9: Mounting

    Select a location out of the radar beam. The radar beam will obstruct or prevent reception of the GPS signal. The location should be well away from a VHF antenna. A GPS receiver is interfered by a harmonic wave of a VHF antenna.

  • Page 10: Wiring

    10 meters, use the optional cable assy. (10 m). Up to four extension cables can be connected serially. Connecting to FURUNO NavNet equipment Connect the antenna cable to the DATA1 port on NavNet equipment. Antenna Cable 10 m Cable assy.
  • Page 11 Connecting to Multi Display RD-30 WAAS is not operative in this installation. Antenna Cable 10 m 12-24 VDC Connecting to Echo Sounder LS-6100 Antenna Cable 10 m AUX port IN/OUT port ECHO SOUNDER LS-6100 NMEA 12 VDC POWER REAR MULTI DISPLAY RD-30 12-24 IN/OUT...

  • Page 12: Connecting To Other Equipment

    *: RS-422 signal can be received by using current loop. Note 1: When connecting FURUNO DGPS beacon receiver GR-80 to this unit, set it as follows: Byte Format, 8-6; First Bit, LSB; Parity Bit, None; Stop Bit, 1; Bit Rate, 8.
  • Page 13 Output/Input data sentences Priority Input Data High XXGGA GPS position status (time of fix, latitude, longitude, receive status, satellite used) XXZDA UTC date (time in minutes and seconds, day, month, year, time) XXGLL Position (latitude, longitude) XXRMC Navigation data (UTC time and latitude, longitude, ground speed, true course, year,...

  • Page 14: Default Settings

    3. DEFAULT SETTINGS Setting Initial Latitude/Longitude Date, Time Antenna Height Almanac Data Ephemeris Data Local Zone Time PDOP Geometric Datum Mask Elevation Disable Satellite Smoothing Coefficient Dynamic Coefficient Data Output (Cycle) DGPS Setting Parameter GEO Satellite, Provider ID WAAS Availability Type 0 Message Default setting North=34°44.0000, East=135°21.0000...

  • Page 15: Troubleshooting, Battery

    If the message “No position data” appears on the display of NavNet equipment, there may be a problem with the GPS receiver. Turn off the power and then check the following points: 1) Check for objects around the antenna which may interfere with reception.

  • Page 16: Specifications

    4. ENVIRONMENTAL CONDITIO N Ambient Temperature Relative Humidity Water proofing Vibration 5. COATING COLOR GP-320B 12 channels parallel, 12 satellites tracking 1 channel 1575.42 MHz C/A code, WAAS All in view, 8-state Kalman filter 10 m (95% of the time, HDOP 4)
  • Page 20 All rights reserved. All rights reserved. Printed in Japan Printed in Japan PUB.No. PUB.No. OME-44220 OME-44220 ( ( YOSH YOSH ) ) GP-320B GP-320B Your Local Agent/Dealer Your Local Agent/Dealer FIRST EDITION : FIRST EDITION : APR. APR. 2002 2002 : JUL.
