14.7

Sample Program of 16-bit Reload Timer

This section gives a program example of the 16-bit reload timer operated in the internal
clock mode and the event count mode:

Program Example in Internal Clock Mode

Processing specification
• The 24 ms interval timer interrupt is generated by the 16-bit reload timer 2.
• The repeated interrupts are generated in the reload mode.
• The timer is started using the software trigger instead of the external trigger input.
2
• EI OS is not used.
• The machine clock is 24 MHz; the count clock is 1.33 µs.
Coding example
ICR04
TMCSR2 EQU
TMR2
TMRLR2 EQU
UF2
CNTE2
TRG2
;--------Main program------------------------------------
CODE
;
LOOP:
EQU 0000B4H
000064H
EQU 00794CH
00794CH
EQU TMCSR2:2
EQU TMCSR2:1
EQU TMCSR2:0
CSEG
:
AND CCR,#0BFH
MOV I:ICR04,#00H
CLRB I:CNTE2
MOVW I:TMRLR2,#4650H ;Set data for 24 ms timer
MOVW I:TMCSR2,#0000100000011011B
MOV ILM,#07H
OR CCR,#40H
:
Processing by user
:
CHAPTER 14 16-BIT RELOAD TIMER
;Interrupt control register for 16-bit
;reload timer
;Timer control status register
;16-bit timer register
;16-bit reload register
;Interrupt request flag bit
;Counter operation enable bit
;Software trigger bit
;Stack pointer (SP), already initialized
;Interrupts disabled
;Interrupt level 0 (highest)
;Counter suspended
;Operation of interval timer,
clock = 1.33 µs
;External trigger disabled, external
output disabled
;Reload mode selected, interrupt enabled
;Interrupt flag cleared, count started
;ILM in PS set to level 7
;Interrupts enabled
