CHAPTER 4 DELAYED INTERRUPT GENERATION MODULE
4.6

Program Example of Delayed Interrupt Generation Module

This section gives a program example of the delayed interrupt generation module.
Program Example of Delayed Interrupt Generation Module
Processing specification
The main program writes "1" to the R0 bit in the delayed interrupt request generate/cancel register (DIRR)
to generate a delayed interrupt request and performs task switching.
Coding example
ICR15
DIRR
DIRR_R0 EQU
;---------Main program------------------------------------
CODE
START:
;---------Interrupt program--------------------------------------
WARI:
;
;
CODE
;---------Vector setting-----------------------------------------
VECT
VECT
90
EQU 0000BFH
EQU 00009FH
DIRR:0
CSEG
AND CCR,#0BFH
MOV I:ICR15,#00H
MOV ILM,#07H
OR CCR,#40H
SETB I:DIRR_R0
LOOP MOV A,#00H
MOV A,#01H
BRA LOOP
CLRB I:DIRR_R0
:
User processing
:
RETI
ENDS
CSEG ABS=0FFH
ORG 0FF54H
DSL WARI
ORG 0FFDCH
DSL START
DB 00H
ENDS
END START
;Interrupt control register
;Delayed interrupt factor generate/
cancel register
;Delay interrupt request generating bit
;Stack pointer (SP),already initialized
;Interrupt disabled
;Interrupt level 0 (strong)
;Setting ILM in PS to level 7
;Interrupt enabled
;Delay interrupt request generating
;No limit loop
;Clear interrupt request flag
;Recovery from interrput
;Setting vector to interrupt #42 (2AH)
;Reset vector setting
;Setting to single-chip mode
