- Page 1 Alcatel-Lucent OmniTouch Fax Server Application Getting Started 8AL_90214_USAA ed.01 Release 5 July, 2007 Alcatel-Lucent Applications All Rights Reserved © Alcatel-Lucent 2007...
- Page 2 Legal Notice Alcatel, Lucent, Alcatel-Lucent and the Alcatel-Lucent logo are trademarks of Alcatel- Lucent. All other trademarks are the property of their respective owners. The information presented is subject to change without notice. Alcatel-Lucent assumes no responsibility for inaccuracies contained herein.
-
Page 3: Table Of Contents
Re-directing the fax domain to the SMTP gateway............3 6.6. Configuring the forms – Modifying the language text ............3 6.7. Configuring the forms – Changing the fax domain ............3 Uninstalling OmniTouch Fax Server ............3 List of abbreviations................3 Alcatel-Lucent Applications Page 3 8AL_90214_USAA ed.01... -
Page 4: Introduction And Purpose Of Document
1. Introduction and purpose of document This guide provides the requirements and installation procedures for OmniTouch Fax Server applications which use the T.38 fax over IP standard. Information on the user permissions needed for the procedures as well as information on basic system configuration will also be provided. -
Page 5: Overall Hardware/Software Requirements
As an example, a 100 GB HDD on the fax server PC will permit the storage of 1 million fax pages. o Ethernet card 2.2. Signaling protocols • SIP/T.38 • H323/T.38 2.3. OXE compatibility • From OXE 6.2 2.4. -
Page 6: Email Client Requirements
Any SMTP based messaging system such as: • Microsoft Outlook, versions 2000 to 2007 Note: The «Collaboration Objects» component of Outlook must be installed. • Lotus Notes fax extension for Lotus R6 and R7 Alcatel-Lucent Applications Page 6 8AL_90214_USAA ed.01... -
Page 7: Pre-Installation Steps
"mysql-4.1.20-1.RHEL4.1.i386". It can then be uninstalled using the following command: # rpm -e mysql-4.1.20-1.RHEL4.1.i386 Note: This may fail due to dependency errors. If that is the case, remove the dependant RPMs before removing MySQL 4.1. Alcatel-Lucent Applications Page 7 8AL_90214_USAA ed.01... -
Page 8: Java Runtime Environment
To upgrade your system's bind library, run the following command: # rpm -Uvh /media/cdrom/3rd/bind/bind-libs-9.2.5-3.i386.rpm 3.6. Apache Tomcat OmniTouch Fax server requires Tomcat 5.5 to run web applications. To install it, run the following commands: # cd /opt # tar -xvzf /media/cdrom/3rd/tomcat/apache-tomcat-5.5.23.tar.gz Alcatel-Lucent Applications Page 8 8AL_90214_USAA ed.01... -
Page 9: Netpbm Programs
CUPS printers. To determine if it is already installed, run the following command: # rpm -qa | grep netpbm-progs If it is not already installed, install it with the following command: # rpm -ivh /media/cdrom/3rd/netpbm/netpbm-progs-10.25-2.EL4.3.i386.rpm Alcatel-Lucent Applications Page 9 8AL_90214_USAA ed.01... -
Page 10: Omnitouch Fax Server Installation Procedure
To do so, perform the following: 1) If necessary stop the currently running service by running: # /etc/init.d/<service_name> status (to see if the service is currently running) # /etc/init.d/<service_name> stop Alcatel-Lucent Applications Page 10 8AL_90214_USAA ed.01... - Page 11 2) Set the required environment variables using: # cd /opt/ofs/scripts && . ./environment 3) Run the service executable with the command line parameter 'console' using: # cd /opt/ofs/Bin && ./<service_name> console Alcatel-Lucent Applications Page 11 8AL_90214_USAA ed.01...
-
Page 12: Forms For Microsoft Outlook
For MS Exchange 2000 and 2003, follow the steps below: Step Action From the MS Exchange – Exchange System Manager, right-click the Connectors node, then from the appearing menu select New > SMTP Connector: –continued– Alcatel-Lucent Applications Page 12 8AL_90214_USAA ed.01... - Page 13 IP address or hostname where the OmniTouch Fax Server SMTP gateway is running. If you use an IP address, be sure to enclose it in square brackets, i.e. [192.168.0.1]. • Add a bridgehead server. –continued– Alcatel-Lucent Applications Page 13 8AL_90214_USAA ed.01...
- Page 14 Other. The Other Address Space Properties dialog window appears as shown below: In the Other Address Space Properties dialog window, complete the following fields as follows: • Type: fax • Cost: 1 • Address: * –continued– Alcatel-Lucent Applications Page 14 8AL_90214_USAA ed.01...
- Page 15 Click OK to close the window. The Properties window will have the new entry now visible in the list, as shown below: –continued– Alcatel-Lucent Applications Page 15 8AL_90214_USAA ed.01...
- Page 16 Click OK; the new OmniTouch Fax Server SMTP connector appears in the Exchange System Manager - Connectors node, as depicted below: –end– Alcatel-Lucent Applications Page 16 8AL_90214_USAA ed.01...
- Page 17 <address of the SMTP gateway> must be replaced with the hostname or IP Note: address where the OmniTouch Fax Server SMTP gateway is running, for example: New-SendConnector –Name OFS –AddressSpace “fax:*;1” –SmartHosts “faxserver.mycompany.com” –DNSRoutingEnabled $false –continued– Alcatel-Lucent Applications Page 17 8AL_90214_USAA ed.01...
-
Page 18: Publishing The Forms
Note: The OmniTouch Fax Server must already be installed. Microsoft Exchange and Outlook 2000 or later must also be installed on individual servers. Outlook must not be set to “Cached Exchange” or offline mode. Alcatel-Lucent Applications Page 18 8AL_90214_USAA ed.01... - Page 19 Step 4. Note 1: To refresh the list of forms, click Reload from list Note 2: To clear the log that appears in the lower half of the window, click Clear log. –continued– Alcatel-Lucent Applications Page 19 8AL_90214_USAA ed.01...
- Page 20 OK button. Note 1: The selected account should have sufficient privileges assigned. Note 2: As each form is published, you may be prompted to enable or disable the macros. Choose Disable Macros. –continued– Alcatel-Lucent Applications Page 20 8AL_90214_USAA ed.01...
-
Page 21: Issues
XP, 2000 or 2003, prevents scripts of any kind from working properly, thus affecting the forms for Microsoft Outlook. A workaround exists, as posted by Microsoft at this location: http://support.microsoft.com/default.aspx?scid=kb;en-us;Q302003 The workaround will instruct you to: Alcatel-Lucent Applications Page 21 8AL_90214_USAA ed.01... - Page 22 Microsoft Outlook 2003 or Microsoft Outlook XP with Service Pack 3. If you are going to view notifications in PDF format, it is recommended that you install one of these versions of Outlook. Using it with any older version may cause the latter to crash unexpectedly. Alcatel-Lucent Applications Page 22 8AL_90214_USAA ed.01...
-
Page 23: Installing Lotus Notes Forms
In the Create Cross Certificate dialog window that appears, click Yes. Note: A dialog window may appear, showing the number of databases processed and the number of errors that occurred (if any). See the Notes Log for details. –end– Alcatel-Lucent Applications Page 23 8AL_90214_USAA ed.01... -
Page 24: Automatic Install
In the Open Database dialog window, select the server where the Fax_Memo_install.nsf and FAXconfiguration.nsf database files are located, in the Server field. Double-click on the Fax folder and then double-click on Fax Memo Install. –continued– Alcatel-Lucent Applications Page 24 8AL_90214_USAA ed.01... - Page 25 Note: NTF stands for Notes Template Facility. These files represent typical Lotus Notes template, a skeleton that contains database design elements, but no documents. Click Open; a new tab appears showing the organization’s Inbox. Click File > Database > Properties. –continued– Alcatel-Lucent Applications Page 25 8AL_90214_USAA ed.01...
- Page 26 Click File > Database > Properties. In the dialog window, click on the fourth tab (refer back to the screenshot in Step 16 of this procedure for a view of the dialog window). –continued– Alcatel-Lucent Applications Page 26 8AL_90214_USAA ed.01...
-
Page 27: Manual Install
Note: Sub-forms are a shared design resource that can be inserted into forms by formula or permanently. Sub-forms are just like forms and usually contain a set of common fields or actions that can be reused in other forms. –continued– Alcatel-Lucent Applications Page 27 8AL_90214_USAA ed.01... - Page 28 Close the dialog window. Click File > Database > Open again or right-click in the workspace and select Open Database. In the Server field of the Open Database dialog window, select the Lotus Notes server. –continued– Alcatel-Lucent Applications Page 28 8AL_90214_USAA ed.01...
-
Page 29: Synchronizing The Mail Template Databases
Click on the Server, and then the Status tabs. Click Server Console in the panel at the left. Type Load design –d mail in the Domino command field at the bottom of the console and then press Enter. –end– Alcatel-Lucent Applications Page 29 8AL_90214_USAA ed.01... -
Page 30: Re-Directing The Fax Domain To The Smtp Gateway
In the Open Database dialog window that appears, select the server where the FAXconfiguration.nsf database file is located, in the Server field. Double-click on the Fax folder and then double-click on Fax Configuration. –continued– Alcatel-Lucent Applications Page 30 8AL_90214_USAA ed.01... -
Page 31: Configuring The Forms - Changing The Fax Domain
Click the Save & Close button to save your changes. Click Close to exit, if you did not make any modifications. If you did some modifications, answer Yes to save them, or No to exit without saving. –end– Alcatel-Lucent Applications Page 31 8AL_90214_USAA ed.01... -
Page 32: Uninstalling Omnitouch Fax Server
# mysqladmin drop -f CompanyConfig -u root --password=faxserver If you would like to remove the OmniTouch Fax Server fax archive, execute the following command: # mysqladmin drop -f FaxArchive -u root --password=faxserver Alcatel-Lucent Applications Page 32 8AL_90214_USAA ed.01... -
Page 33: List Of Abbreviations
Portable document format Public switched telephone network PSTN Random access memory Redhat packet manager SATA Serial advanced technology attachment Session initiating protocol SMTP Simple mail transfer protocol Transmission control protocol VoIP Voice over internet protocol Alcatel-Lucent Applications Page 33 8AL_90214_USAA ed.01... - Page 34 www.alcatel-lucent.com...
