Voice over WLAN Mobile IP Touch Design Guide R2.0
Pre-Sales Communication
Voice over WLAN MIPT Design Guide R2.0
OmniPCX Enterprise R7.1
ESD/ Central Pre Sales / DF/ PH
1/45
January 2007 – Ed 01
All rights reserved © 2007 Alcatel-Lucent

Advertisement

Table of Contents
loading

Related Manuals for Alcatel-Lucent OmniPCX Enterprise R7.1

Summary of Contents for Alcatel-Lucent OmniPCX Enterprise R7.1

  • Page 1 Voice over WLAN Mobile IP Touch Design Guide R2.0 Pre-Sales Communication Voice over WLAN MIPT Design Guide R2.0 OmniPCX Enterprise R7.1 ESD/ Central Pre Sales / DF/ PH 1/45 January 2007 – Ed 01 All rights reserved © 2007 Alcatel-Lucent...

  • Page 2: Table Of Contents

    Introduction & Objectives ....................6 1.1. Operational Components .....................6 1.1.1. OmniPCX Enterprise Applications Specific Elements ..........6 1.1.2. VoWLAN Infrastructure (MIPT SVP Server) ...............6 1.1.3. WLAN Infrastructure (Provided by Alcatel-Lucent) ............7 1.1.4. Server Elements (DHCP, TFTP, Management) ............9 1.1.4.1. DHCP Server 1.1.4.2. TFTP Server 1.1.4.3.
  • Page 3 Voice over WLAN Mobile IP Touch Design Guide R2.0 2.3.6. Layer 3 & 4 Filtering (ACL & Packet Inspection) .............21 2.3.7. Auxiliary Security Measures ..................21 Design Process for VoWLAN ....................22 3.1. Pre Sale Data Collection .....................22 3.1.1. Physical Diagram (to include existing wireless technologies)........22 3.1.2.
  • Page 4 7.1.2. VoWLAN section of the PreSales Presentations: .............44 7.1.3. Multi-Vendor section for compatibility:..............44 7.1.4. VoWLAN section of the PCS Process (non-Alcatel-Lucent WLAN infra): ....44 Annex ..........................45 8.1. Site Survey Tool ......................45 Figure 1: MIPT Icons ........................14 Figure 2: Dial by Name ......................15 Figure 3: Notification.........................15...
  • Page 5 Voice over WLAN Mobile IP Touch Design Guide R2.0 Figure 9: IP Addressing Plan ......................23 Figure 10: Logical paths for Voice and Data VLANs ..............23 Figure 11: Floor Map (with scale & legend).................24 Figure 12: Single OXE Node and Multi-SVP Servers..............27 Figure 13: Multi-Node and Multi-SVP ..................27 Figure 14: Layer 2 considerations ....................28 Figure 15: Layer 3 considerations ....................29...

  • Page 6: Introduction & Objectives

    It is the intent of this guide to aid Sales Engineers in designing and selling telecommunications solutions Incorporating Alcatel-Lucent’s Mobile IP Touch (MIPT) Voice over Wireless LAN (VoWLAN) solution (R2.0) This document has been created specifically in the context of an architectural and technical Pre-Sales Design Guide approach.

  • Page 7: Wlan Infrastructure (Provided By Alcatel-Lucent)

    Access Point saturation to provide strong QoS; this is a mandatory MIPT VoWLAN element. 1.1.3. WLAN Infrastructure (Provided by Alcatel-Lucent) OmniAccess 4302: Equipped with one Fast Ethernet port (10/100) and one Gigabit Ethernet port (10/100/1000). Used to support a maximum of 6 AP in overlay mode only.
  • Page 8 Voice over WLAN Mobile IP Touch Design Guide R2.0 OmniAccess 6000: Four slot modular chassis used to support a maximum of 512 AP. Equipped with up to seventy- two 10/100 Ethernet ports and six GBIC uplink modules for flexible LAN applications. Imbedded Stateful Inspection firewall options allow for robust OmniAccess 6000 security solutions.

  • Page 9: Server Elements (Dhcp, Tftp, Management)

    Alcatel-Lucent openly recognizes the challenges faced by customers with existing 802.11 network implementations. For this reason, Alcatel-Lucent also seeks to support Mobile IP Touch - Voice over Wireless Local Area Network solutions on a variety of approved third-party infrastructure architectures.

  • Page 10: Tftp Server

    After the radio network is operational, the goal of RF Spectrum Management changes to that of tuning and adjusting radio parameters in order to maintain a high degree of performance. With Alcatel- Lucent, RF Spectrum Management is largely automatic, requiring little configuration or intervention from the administrator.

  • Page 11: Mobile Ip Touch Terminals

    1.1.5. Mobile IP Touch Terminals 1.1.5.1. MIPT Description Alcatel-Lucent makes two MIPT models available, one each for office and industrial use. The performance of these two handsets is very similar but their designs and options are focused for use in specific environments.
  • Page 12 Voice over WLAN Mobile IP Touch Design Guide R2.0 Swivel Clip for MIPT 300: Offering easy removal of battery, interchangeable clips for simple attachment to clothing. Charging Stands: The MIPT 300 and MIPT 600 each have an option for a model specific Charging Stand.

  • Page 13: Mipt Configuration Tool

    Voice over WLAN Mobile IP Touch Design Guide R2.0 1.1.5.3. MIPT Configuration Tool Configuration cradle: One MIPT set configuration at a time One slot per MIPT set type. MIPT set configuration via Windows-PC (RS-232 serial interface to PC). Direct upload or download from/to the MIPT set flash memory.

  • Page 14: Mipt Features

    Voice over WLAN Mobile IP Touch Design Guide R2.0 1.1.5.4. MIPT Features 1.1.5.4.1. Customizable Rings on MIPT 300 and 600: Ring Tone, Ring Delay, Ring Cadence and Vibrate Cadence parameters can all be adjusted independently to meet individual call notification preferences. 1.1.5.4.2.

  • Page 15: Noe Features

    Voice over WLAN Mobile IP Touch Design Guide R2.0 1.1.6. NOE features Since OmniPCX Enterprise Rel 7.1 the MIPT set has integrated NOE feature (Dial by Name, Notification for Messaging, etc.) and as a result can be globally considered as an IP Touch set, but limited by its ergonomics.

  • Page 16: Operational Modes And Considerations

    Being as no two customer network environments are exactly the same, it is critical for technology such as VoWLAN to possess a great degree of flexibility. Alcatel-Lucent’s MIPT solution is not exempt from this requirement. The following section highlights some MIPT architectural adaptabilities.

  • Page 17: Appliance/Overlay Mode

    In Appliance Mode operation, Access Points are not directly attached to Alcatel-Lucent OmniAccess Wireless Switches. In this type of operational mode, the Alcatel-Lucent OmniAccess Wireless Switch acts only as an Access Point Controller and does not directly host AP via local 10/100 ports.
  • Page 18 Much like the above discussed Inline Power Injector, Inline Power Patch Panels can be used to achieve the same effect when more than a few devices require IEEE 802.3af power. Alcatel-Lucent offers Power Patch Panels in 6, 12, and 24 port varieties.

  • Page 19: Quality Of Service

    MIPT handset. No infrastructure facility (such as IEEE 802.11e) is presently included in Alcatel-Lucent’s MIPT VoWLAN R2.0 solution to provide for QoS from the MIPT handset towards the wired LAN. For prioritization from the MIPT handset in the wireless environment towards the wired LAN, only proprietary methods and adaptations of the IEEE 802.11 PIFS (PCF Interframe Spacing) option are...

  • Page 20: Security

    Security is always a sensitive topic to discuss, and opinions on how best to provide for it vary greatly from one engineer to the next. With this in mind, Alcatel-Lucent is constantly developing the list of security options available within the MIPT VoWLAN solution offer to satisfy as many different opinions as possible.

  • Page 21: Mac Address Filtering

    2.3.3. MAC Address Filtering MAC address filtering facilities are provided for within Alcatel-Lucent’s OmniAccess product platforms. Alcatel-Lucent strongly encourages the use of Local MAC address filter rules to help ensure that only authorized wireless clients are permitted to join the VoWLAN network.

  • Page 22: Design Process For Vowlan

    3. Design Process for VoWLAN 3.1. Pre Sale Data Collection In order to prepare an Alcatel-Lucent VoWLAN solution, several pieces of documentation must be sourced from the customer. The accuracy of a final system proposal is directly related, in most cases, to the amount and quality of information collected prior to initiating design formulation.

  • Page 23: Logical Diagram

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.1.2. Logical Diagram Logical Diagrams are also critical for complete and accurate solution construction. The logical diagram must include information related to the existing customer VLAN strategy, QoS policies, Security measures, redundancy and fault tolerance schemes, as well as future provisioning and traffic shaping. Information gathered from the logical diagrams will determine IP addressing schemes, security measures, and VLAN mapping as well as influence certain physical design options (ideal SVP Server location, ideal TFTP &...

  • Page 24: Floor Level Maps/Diagrams

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.1.3. Floor Level Maps/Diagrams To complete detailed planning, a floor level diagram is required. This floor level diagram can be used in the design process in two different ways, Prediction Planning and for the Site Survey. This diagram does not necessarily need to include detail on how desks are situated within office and where toilets and potted plants are located within restroom, but walls, dividers, elevators, pillars, windows, doors, and other obstacles should be clearly marked and to scale.

  • Page 25: Customer Specific Application & Design Considerations

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.2. Customer Specific Application & Design Considerations Due to the fact that Alcatel-Lucent’s MIPT VoWLAN solution is being offered in a multi-stage fashion with evolving capabilities, it is important for the design engineer to compare expected customer usage patterns against current MIPT release restrictions before proposing an Alcatel-Lucent MIPT VoWLAN solution.

  • Page 26: Network Topologies

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.2.2. Network Topologies VoWLAN topologies have quickly evolved since OmniPCX Release 7.1 (MIPT 2.0). Now a single Com server can drive several SVP Servers, each SVP Server being in a separate VLAN/IP subnets).

  • Page 27: Single Oxe Node And Multi-Svp Servers (Cascaded Or Not)

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.2.2.6. Single OXE Node and Multi-SVP Servers (Cascaded or not) Figure 12: Single OXE Node and Multi-SVP Servers MIPT rel 2.0 topology has evolved by making possible managing several SVP Servers from the same Com Server (out of cascading purpose).

  • Page 28: Layer 2 Considerations (Svp Server And Mipt)

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.2.2.8. Layer 2 considerations (SVP Server and MIPT) Figure 14: Layer 2 considerations Layer 2 configuration means that SVP server and MIPT sets are in the same Voice VLAN/IP subnet. This topology allows quick handover. ESD/ Central Pre Sales / DF/ PH 28/45 January 2007 –...

  • Page 29: Layer 3 Considerations (Svp And Mipt)

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.2.2.9. Layer 3 considerations (SVP and MIPT) Figure 15: Layer 3 considerations Layer 3 configuration means that the SVP server and MIPT sets can be in different VLANs/IP subnets. In this case WLAN switches and APs must be configured in layer 3. This topology is fully adapted to routed data network environment Jitter must be less than 1ms between AP and SVP Server.

  • Page 30: Roaming And Handover

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.3. Roaming and Handover 3.3.1. Roaming definition Refers to the ability to be reached (ie: making and receiving calls) in a different Site or Network. Inside a site or a network, provides a wireless device the capability to associate to an AP after a power-on or a reset of this device.

  • Page 31: G711 Considerations

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.4. G711 considerations Node A Node A Node B Node B SVP Server A SVP Server A SVP Server B SVP Server B CS A CS A CS B CS B Inter-Node Inter-Node G711...

  • Page 32: Mipt 2.0 Specifications

    MIPT VoWLAN terminals are restricted to 802.11b network environments. Alcatel-Lucent’s MIPT VoWLAN R2.0 solution is based on IEEE 802.11b technology. Alcatel-Lucent offers support for IEEE 802.11g and IEEE 802.11a data subscribers via the OmniAccess range or products, but only supports IEEE 802.11b MIPT sets (provided by Alcatel-Lucent).

  • Page 33: Security

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.6.3. Security WEP (128 bits) WPA (PSK with TKIP) WPA2 (PSK with AES) 3.6.4. Roaming and Handover Roaming and Handover are topology dependent (see chapter Roaming and Handover)and require: A common SSID Common Security rules to be applied to all WLAN switches (Same WEP key or WPA/WPA2 passphrase) ESD/ Central Pre Sales / DF/ PH...

  • Page 34: Vowlan Multi-Vendor Design In R2.0

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.7. VoWLAN Multi-Vendor Design in R2.0 Warning : all previously studied VoWLAN topologies built on Alcatel-Lucent WLAN infra do not apply for a non-Alcatel-Lucent WLAN infra. The Inplementation of the Alcatel-Lucent MIPT R2.0 solution on a Non Alcatel-Lucent WLAN infra (Aironet, Nortel, Trapeze, etc.) may involve some limitations in terms of VLAN, Roaming/Handover, quantity of...

  • Page 35: Converged Wireless Environments (Voice & Data Combinations)

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.7.1. Converged Wireless Environments (Voice & Data Combinations) One of the most significant reasons that businesses look to use wireless LAN technology to support voice is the desire to have a single infrastructure for both voice and data services. While this may at first sound like a very simple thing to implement, it often is far more complex to design than most customers originally anticipate.

  • Page 36: Voice On 802.11B, Data On 802.11A

    10-13 non- overlapping channels (depending on local market restrictions) it makes available. Customers seeking this type of solution can unify the infrastructure elements by using Alcatel-Lucent’s OmniAccess product suite for both Wi-Fi formats. Alcatel-Lucent’s OmniAccess 70 Access Point can be effectively leveraged to construct networks for both 2.4 GHz (802.11b/g) and 5 GHz (802.11a) networks...

  • Page 37: Predictive Environment Solution Options (Responding To Rfx)

    Voice over WLAN Mobile IP Touch Design Guide R2.0 3.8. Predictive Environment Solution Options (Responding to RFx) When answering an RFP or RFI, normally, there is little possibility of scheduling a Site Survey for various reasons: Building under construction or not yet built, short delay to answer the RFP, fair competition clause, etc.

  • Page 38: Predictive Tool Coverage Planning

    802.11 data clients with typical power and sensitivity specifications. It is for this reason that the use of predictive planning tools is not currently recommended by Alcatel-Lucent. Even in the case of Alcatel-Lucent's predictive planning tool, the unique operational characteristics of MIPT handsets can not be taken into full consideration, resulting in often flawed and under-engineered proposals.

  • Page 39: Environment Verification & Validation

    Audit is mandatory for all solutions prior to installation. Alcatel-Lucent’s OmniAccess platform family can be used to support data as well as voice. For solutions that propose both voice and data coverage, it is important to distinguish between the needs of the voice and data elements.

  • Page 40: Post Install Survey

    As a general rule, Alcatel-Lucent recommends re-evaluation whenever new technology demand is generated or roughly every 18 months. Some customers may be able to happily use VoWLAN technology in a static environment for many years without a renewed survey, others may find that continuous evolution of network demands require a validation every six months.

  • Page 41: Design Examples

    Voice over WLAN Mobile IP Touch Design Guide R2.0 5. Design Examples 5.1. Configuration for up to 4 AP (Demo or small area coverage) This configuration example depicts a model well adapted to a Demo context for up to 4 AP without a customer need for WLAN controller redundancy.

  • Page 42: Configuration For Up To 16 Ap (With Redundancy)

    Voice over WLAN Mobile IP Touch Design Guide R2.0 5.3. Configuration for up to 16 AP (with redundancy) This configuration example depicts a model for up to 16 AP with WLAN controller redundancy. Figure 22: Configuration for up to 16 AP (with redundancy) In this scenario, the backup process takes place between the 2 WLAN Switches OA4308.

  • Page 43: Quotes & Orders

    Unfortunately, the quotation process for the MIPT VoWLAN R2.0 solution is not fully automated within ACTIS as many of Alcatel-Lucent’s other voice technologies. For this reason, engineers are strongly encouraged to complete the framework of the target VoWLAN design prior to beginning the ACTIS process.

  • Page 44: Reference Documents

    • KD_10_ MIPT_2-0_Case_study_ed3 BPWS Path: 7.1.3. Multi-Vendor section for compatibility: • http://www.spectralink.com/consumer/resources/wifi_compatibility.jsp 7.1.4. VoWLAN section of the PCS Process (non-Alcatel-Lucent WLAN infra): • PCS Process Information Form VoWLAN BPWS Path: ESD/ Central Pre Sales / DF/ PH 44/45 January 2007 – Ed 01...

  • Page 45: Annex

    The correct placement for these Access Points Figure 23: Site Survey components The Site Survey tool is mainly used by Alcatel-Lucent Professional Services and Business Partners. A site Survey is required every time it is needed to perform a quotation for VoWLAN implementation. A VoIP audit is also necessary.
