Table valiation
Wave Shape:0
Type (Wave Shap Type)
1: The signal after wave shaping will be output
without further change. If "Shape" is set to the
minimum value, the phase modulated signal will be
output essentially without change.
2: A rounded waveform will be obtained regardless of
the "Shape" value.
AMS1 (Alternate Modulation Source 1)
Selects a modulation source 1 ( p.48 of this manual)
that will control "Wave Shape" value.
Intensity (Shape AMS1 Intensity)
Specifies the depth and direction of the effect of "AMS1."
AMS2 (Alternate Modulation Source 2)
Selects a modulation source 2 ( p.48 of this manual)
that will control "Wave Shape" value.
Intensity (Shape AMS2 Intensity)
Specifies the depth and direction of the effect of "AMS2."
Feedback
Specifies the amount of the output after wave shaping
that will be fed back to the carrier.
1–3b: Modulator
Wave
[Saw, Square, Triangle, Sine, OSC2(1), Sub OSC,
Filter1, Filter2]
Select the waveform of the modulator.
This selects the other oscillator or sub oscillator etc.
If you set this to OSC2(1) , SubOSC , Filter 1
Filter 2 , the Frequency Coarse
settings will not be available.
Level
Specifies the output level of the modulator.
This value will determine the amount of modulation
that is applied to the "1–3a: Carrier" setting.
AMS1 (Alternate Modulation Source 1)
Selects a modulation source 1 ( p.48 of this manual)
that will control "Level."
Wave Shape:99
[1, 2]
[Off...MIDI:CC#83]
[–99...+99]
[Off...MIDI:CC#83]
[–99...+99]
[0...99]
, or
and following
[0...99]
[Off...MIDI:CC#83]
Intensity (Level AMS1 Intensity)
Specifies the depth and direction of the effect of
"AMS1."
AMS2 (Alternate Modulation Source 2)
Selects a modulation source 2 ( p.48 of this manual)
that will control "Level."
Intensity (Level AMS2 Intensity)
Specifies the depth and direction of the effect of
"AMS2."
Frequency Coarse
Specifies a multiplication factor which will be applied
to the pitch of the modulator, relative to the "1–3a:
Carrier" setting.
Fine
Makes fine adjustments to the pitch of the modulator.
AMS1 (Alternate Modulation Source 1)
Selects a modulation source 1 ( p.48 of this manual)
that will control the pitch of the modulator.
Intensity (Frequncy AMS1 Intensity)
Specifies the depth and direction of the effect of
"AMS1."
AMS2 (Alternate Modulation Source 2)
Selects a modulation source 2 ( p.48 of this manual)
that will control the pitch of the modulator.
Intensity (Frequncy AMS2 Intensity)
Specifies the depth and direction of the effect of
"AMS2."
[–99...+99]
[Off...MIDI:CC#83]
[–99...+99]
[0.5, 1...16]
[–50...+50]
[Off...MIDI:CC#83]
[–99...+99]
[Off...MIDI:CC#83]
[–99...+99]
