Web Server
Local
(if enabled)
Multiple Registrations
Configuration file:
Central
sip.cfg
(boot server)
Configuration file:
phone1.cfg
For one-touch voice mail access, enable the "one-touch voice mail"
user preference and bypass instant messages to remove the step of
selecting between instant messages and voice mail after pressing the
Messages key on the SoundPoint IP 430, 500, 501, 550, 560, 600,
601, and 650 (instant messages are still accessible from the Main
Menu).
Navigate to http://<phoneIPAddress>/coreConf.htm#us
On a per-registration basis, specify a subscribe contact for solicited
NOTIFY applications, a callback mode (self call-back or another
contact) to call when the user accesses voice mail.
Navigate to http://<phoneIPAddress>/reg.htm
Changes are saved to local flash and backed up to <Ethernet
address>-phone.cfg on the boot server. Changes will permanently
override global settings unless deleted through the Reset Local
Config menu selection and the <Ethernet address>-phone.cfg is
removed from the boot server.
The SoundPoint IP 301, 320, 330, and 430 support a maximum of two
registrations, the SoundPoint IP 501 supports three, the SoundPoint IP 550 and
560 supports four, and the SoundPoint IP 600, 601, and 650 support 6. Up to
three SoundPoint IP Expansion Modules can be added to a single host
SoundPoint IP 601 and 650 phone increasing the total number of buttons to 12
registrations on the IP 601 and 34 registrations on the IP 650. The SoundStation
IP 4000 supports a single registration.
Each registration can be mapped to one or more line keys (a line key can be
used for only one registration). The user can select which registration to use for
outgoing calls or which to use when initiating new instant message dialogs.
Configuration changes can performed centrally at the boot server or locally:
Specify the local SIP signaling port and an array of SIP servers to
register to. For each server specify the registration period and the
signaling failure behavior.
For more information, refer to
•
Server <server/>
For up to maximum number of registrations, specify a display name,
a SIP address, an optional display label, an authentication user ID
and password, the number of line keys to use, and an optional array
of registration servers. The authentication user ID and password are
optional and for security reasons can be omitted from the
configuration files. The local flash parameters will be used instead.
The optional array of servers and their associated parameters will
override the servers specified in sip.cfg if non-Null.
For more information, refer to
•
Local <local/>
on page A-7.
Registration <reg/>
Configuring Your System
on page
A-6
and
on page A-89.
4 - 37
