Specifications; Audio Input; Video Input; Video Output - Extron electronics System 5 IP Series Specification Sheet

System 5 IP Series
System 5 IP Series Accessories
incLuded AcceSSorieS
NETXC M-M
MBD 149
oPtionAL AcceSSorieS
SCP 104
SCP 226
IRCM-DV+
IR 402
IR Emitter and Shield Kit
IR Emitter and Shield - Dual Kit
IR Link
CFG Cable
UC50' (50' / 15 m)
MLSC 406/506/5IP-35'
System 5 IP Labels

SPeciFicAtionS

Video
Gain . . . . . . . . . . . . . . . . . . . . . . Unity
Bandwidth . . . . . . . . . . . . . . . . 350 MHz (-3 dB), fully loaded

Video inPut

Number/signal type . . . . . . . . 1 RGBHV, RGBS, RGsB, RsGsBs
2 RGBHV, RGBS, RGsB, RsGsBs, S-video, or composite video
2 S-video or composite video
Connectors . . . . . . . . . . . . . . . . (1) 15-pin HD female (RGB)
2 x 5 female BNCs (RGB, S-video, or composite video)
2 x 1 female BNC (composite video) and (1) 4-pin mini DIN (S-video)
Impedance . . . . . . . . . . . . . . . . 75 ohms
Horizontal frequency. . . . . . . . 15 kHz to 145 kHz
Vertical frequency . . . . . . . . . . 30 Hz to 170 Hz

Video outPut

Number/signal type . . . . . . . . 1 RGBHV, RGBS, RGsB, RsGsBs
1 S-video
1 composite video
Connectors . . . . . . . . . . . . . . . . 5 female BNCs (RGB)
2 female BNCs (S-video)
1 female BNC (composite video)
Nominal level . . . . . . . . . . . . . . 1 Vp-p for Y of S-video, and for composite video
0.7 Vp-p for RGB
0.3 Vp-p for C of S-video
Minimum / Maximum levels
RGB . . . . . . . . . . . . . . . . . . . . . . Analog: 0.3 V to 1.5 Vp-p (follows input)
S-video, composite video . . . . . Analog: 0.4 V to 2.0 Vp-p (follows input)
Impedance . . . . . . . . . . . . . . . . 75 ohms
Return loss . . . . . . . . . . . . . . . . <-40 dB @ 5 MHz
DC offset . . . . . . . . . . . . . . . . . . ±5 mV with input at 0 offset
Switching type . . . . . . . . . . . . . Triple-Action™ (RGB delay)
Sync
Input type . . . . . . . . . . . . . . . . . RGBHV, RGBS, RGsB, RsGsBs
Output type . . . . . . . . . . . . . . . RGBHV, RGBS, RGsB, RsGsBs (follows input)
Input level . . . . . . . . . . . . . . . . 2.0 V to 5.0 Vp-p
Output level . . . . . . . . . . . . . . . 5.0 Vp-p, unterminated
Input impedance . . . . . . . . . . . 10k ohms
Output impedance. . . . . . . . . . 75 ohms
Max. propagation delay . . . . . 30 ns
Max. Rise/fall time . . . . . . . . . 4 ns
Audio
Gain
Lineout . . . . . . . . . . . . . . . . . . . . Unbalanced output: 0 dB; balanced output: +6 dB
Preamp . . . . . . . . . . . . . . . . . . . Unbalanced output: -6 dB; balanced output: 0 dB at max. volume
Frequency response,
amplifier models
Power amp (4 or 8 ohm) . . . . . . 20 Hz to 20 kHz, 0 dB to -1.5 dB @ 1 watt output
Lineout/preamp . . . . . . . . . . . . . 20 Hz to 20 kHz, 0 dB to -0.5 dB
Frequency response,
non amplifier models
Lineout/preamp . . . . . . . . . . . . . 20 Hz to 20 kHz, 0 dB to -0.5 dB
THD + Noise . . . . . . . . . . . . . . . <0.15% @ 1 kHz at max. power output
S/N at max. power output or
line level output, unweighted
Power amp
(amplifier models only) . . . . . . . >80 dB at 10 Hz to 22 kHz
Preamp . . . . . . . . . . . . . . . . . . . >-100 dB at 20 Hz to 20 kHz
Lineout . . . . . . . . . . . . . . . . . . . . >-110 dB at 10 Hz to 22 kHz
Crosstalk . . . . . . . . . . . . . . . . . <-80 dB @ 1 kHz, fully loaded
CMRR . . . . . . . . . . . . . . . . . . . . >80 dB @ 20 Hz to 200 Hz, >60 dB @ 20 Hz to 20 kHz
266
modeL deScriPtion
Male to Male RJ-45 Network Crossover Cable, 6'
1U, Full Rack Width, Rack Mount and Through-Desk Kit for
Four-Piece Enclosure
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
modeL deScriPtion
Secondary Control Panel for MLC 104 IP Plus and System 5 IP
Secondary Control Panel for MLC 226 IP and System 5 IP
Dual-Function DVD and VCR IR Control Module
Handheld IR Remote Control for System 5 IP and MLC 226 IP
IR Emitter Kits
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
IR Emitter Kits
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wall-Mountable IR Signal Repeater
9-pin D Female to 2.5 mm TRS Configuration Cable
Female 9-pin D Connector to Unterminated - Captive Screw Ready
One Pre-terminated SY VGA and Composite Video Cable, and One S-Video
Adapter Cable - Plenum
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I/O Descriptor Labels
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
USA West USA West
+1.714.491.1500 / +800.633.9876 +1.714.491.1500 / +800.633.9876
+1.714.491.1517 FAX +1.714.491.1517 FAX
(1.8 m)
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .

Audio inPut

Number / Signal type . . . . . . . 4 stereo or mono, balanced/unbalanced (inputs 1-4)
1 stereo or mono, unbalanced (input 5)
Connectors . . . . . . . . . . . . . . . . (4) 3.5 mm captive screw connectors, 5 pole (inputs 1-4)
(1) 3.5 mm mini audio jack (tip, ring, sleeve) (input 5)
Impedance . . . . . . . . . . . . . . . . >10k ohms unbalanced
Nominal level . . . . . . . . . . . . . . -10 dBV (316 mVrms)
Input gain adjustment . . . . . . -40 dB to +30 dB, adjustable per input
Audio outPut — Line LeVeL
Number / Signal type . . . . . . . 2 stereo or mono, balanced/unbalanced (1 fixed and 1 variable)
Connectors . . . . . . . . . . . . . . . . (2) 3.5mm captive screw connectors, 5 pole
Impedance . . . . . . . . . . . . . . . . 50 ohms unbalanced, 100 ohms balanced
Nominal level . . . . . . . . . . . . . . -10 dBV (316 mV) or +4 dBu (1.23 V) (configurable)
Audio outPut — Power AmPLiFier
Number / Signal type . . . . . . . 1 stereo or mono
Connector . . . . . . . . . . . . . . . . . (1) 4 position screw terminal
Sensitivity. . . . . . . . . . . . . . . . . -22 dBV (80 mVrms, -19.8 dBu) for max. power output (adjustable)
Power bandwidth at rated maximum power output
4 ohm output . . . . . . . . . . . . . . . 10 Hz to 20 kHz, 0.5% THD
8 ohm output . . . . . . . . . . . . . . . 20 Hz to 20 kHz, 0.8% THD
Drive / Full power out . . . . . . . 40 watts; 20 watts (rms) per channel, 4 or 8 ohm load
Protection . . . . . . . . . . . . . . . . . Input limiting, thermal, short circuit
controL / remote — Switcher
Serial control port . . . . . . . . . . 2 RS-232: 1 rear panel 9-pin female D connector,
1 front panel 2.5 mm stereo mini jack
Ethernet control port . . . . . . . 1 RJ-45 female
Ethernet data rate . . . . . . . . . . 10/100Base-T, half/full duplex with autodetect
Ethernet protocol . . . . . . . . . . ARP, DHCP, ICMP (ping), TCP/IP, Telnet, HTTP, SMTP
Web server . . . . . . . . . . . . . . . . 7.25 MB nonvolatile user memory
controL — reLAy
Number / Type . . . . . . . . . . . . . 6 momentary or latching (configurable via software)
Connectors . . . . . . . . . . . . . . . . (3) 3.5 mm captive screw connectors, 3 pole
Contact rating . . . . . . . . . . . . . 24 V, 1A
controL — Projector
Projector control port
(RS-232) . . . . . . . . . . . . . . . . . . (1) 3.5 mm captive screw connector, 3-pole
controL — PeriPherAL equiPment
IR / Serial control ports . . . . . (4) 3.5 mm captive screw connectors, 2-pole
Programmable: RS-232 (±5 V), or TTL level (0 to 5 V) infrared up to 1 MHz
GenerAL
Power . . . . . . . . . . . . . . . . . . . . 100 VAC to 240 VAC, 50/60 Hz, 50 watts, internal, universal
Temperature / Humidity . . . . . Storage -40° to +158°F (-40° to +70°C) / 10% to 90%, noncondensing
Operating +32° to +122°F (0° to +50°C) / 10% to 90%, noncondensing
Rack mount . . . . . . . . . . . . . . . Yes, with included brackets
Enclosure type . . . . . . . . . . . . . Metal
Enclosure dimensions . . . . . . 1.75" H x 17.5" W x 9.4" D (1U high, full rack wide)
4.4 cm H x 44.4 cm W x 23.9 cm D
Product weight . . . . . . . . . . . . 6.0 lbs (2.7 kg)
Shipping weight . . . . . . . . . . . 11 lbs (5 kg)
DIM weight
USA / Canada . . . . . . . . . . . . . . 10 lbs (5 kg)
International . . . . . . . . . . . . . . . . 11 lbs (5 kg)
Vibration . . . . . . . . . . . . . . . . . . ISTA 1A in carton (International Safe Transit Association)
Listings . . . . . . . . . . . . . . . . . . . UL, CUL
Compliances . . . . . . . . . . . . . . CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF . . . . . . . . . . . . . . . . . . . . . 30,000 hours
Warranty . . . . . . . . . . . . . . . . . . 3 years parts and labor
NOTE: All nominal levels are at ±10%. Specifications are subject to change without notice.
USA east USA east
+1.919.863.1794 / +800.633.9876 +1.919.863.1794 / +800.633.9876
+1.919.863.1797 FAX +1.919.863.1797 FAX
S y S t e m S w I t c h e r S
PAGe PArt #
page 797 26-591-01
page 817 70-077-03
PAGe PArt #
page 273 60-672-02
page 400 60-671-02
page 393 70-220-02
page 415 70-207-01
page 281 70-283-01
page 281 70-283-02
page 281 60-404-02
page 282 70-335-01
n/a 26-518-01
page 444 42-097-35
n/a 33-953-02
(Amplifier modelS only)
