Installation and Operation, cont'd

Operation

1. Make sure that all the input and output devices and the
switcher are powered on.
2. If the switcher is in manual switching mode, select an input
from the front panel buttons or by using the contact
closure controller.
3. If the switcher is in auto-switching mode (rear panel
AS/REMOTE pins 4 and 5 are jumpered together), the
switcher will automatically select the highest numbered
input with an active sync signal.
4. The image should now appear on screen, and sound from
the audio source should be audible.

Troubleshooting

If the image does not appear or there is no sound
1. Ensure that all devices are plugged in to a power source.
2. Make sure that each device is receiving power.
If the switcher is in manual switch mode, one of the input
indicator LEDs should light on the front panel of the
SW2 VGA DA2 AF R. If the switcher is in auto-switching
mode and there is no active incoming sync signal detected,
the input indicator LEDs will not light. However, the auto-
switching indicator LED should light when the auto-
switching mode is on. If no LED lights, check to make sure
the power connector is properly wired and neither
conductor is connected to the middle pole.
3. Check the cabling and the audio connector wiring, and
make adjustments as needed.
4. Select a different input to check for a display and sound.
www.camboard.de
2-12 SW2 VGA DA2 AF R • Installation and Operation
CAMBOARD Electronics
SW2 VGA DA2 AF R
Accessories and Part Numbers
Tel. 07131 911201
Fax 07131 911203
A
Appendix

Specifications,

Specifications

Included Parts

Accessories

Adapter
Adapter Plates
