fcFxlogiNxPortIndex [fcFxlogiTable]
Syntax
FcFeNxPortIndex
Access
Read-only
Status
Mandatory
Description
The object identifies the associated NxPort in the attachment for which the entry contains
information.
fcFxPortFcphVersionAgreed [fcFxlogiTable]
Syntax FcphVersion
Access Read-only
Status Mandatory
Description
The version of FC-PH that the FxPort has agreed to support from the Fabric Login.
fcFxPortNxPortBbCredit [fcFxlogiTable]
Syntax FcBbCredit
Access Read-only
Status Mandatory
Description The total number of buffers available for holding Class 1 connect-request, Class 2 or Class 3 frames
to be transmitted to the attached NxPort. It is for buffer- to-buffer flow control in the direction from
FxPort to NxPort. The buffer-to-buffer flow control mechanism is indicated in the respective
fcFxPortBbCreditModel.
fcFxPortNxPortRxDataFieldSize [fcFxlogiTable]
Syntax FcRxDataFieldSize
Access Read-only
Status Mandatory
Description The Receive Data Field Size of the attached NxPort. This is a binary value that specifies the largest
Data Field Size for an FT_1 frame that can be received by the NxPort. The value is in number of
bytes and ranges from 128 to 2112 inclusive.
