fcFxPortPhysAdminStatus [fcFxPortPhysTable]
Syntax
Value
Integer
Access Read-write
Status
Mandatory
Description
The desired state of the FxPort. A management station may place the FxPort in a desired state by
setting this object accordingly. The 3 (testing) state indicates that no operational frames can be
passed. When a Fabric Element initializes, all FxPorts start with fcFxPortPhysAdminStatus in the 2
(offline) state. As the result of either explicit management action or per configuration information
accessible by the Fabric Element, fcFxPortPhysAdminStatus is then changed to either the 1
(online) or 3 (testing) states, or remains in the 2 (offline) state.
fcFxPortPhysOperStatus [fcFxPortPhysTable]
Syntax
Value
Integer
Note:
Access
Read-only
Status
Mandatory
Description
The current operational status of the FxPort. The 3 (testing) indicates that no operational frames can
be passed. If fcFxPortPhysAdminStatus is 2 (offline) then fcFxPortPhysOperStatus should be 2
(offline). If fcFxPortPhysAdminStatus is changed to 1 (online) then fcFxPortPhysOperStatus
should change to 1 (online) if the FxPort is ready to accept Fabric Login request from the attached
NxPort; it should proceed and remain in the 4 (link-failure) state if and only if there is a fault that
prevents it from going to the 1 (online) state.
MIB Reference Manual Version 3.0
Declaration
1 (online)
2 (offline)
3 (testing)
Declaration
1 (online)
2 (offline)
3 (testing)
4 (link-failure)
Other values may be used to indicate diagnostic for failed test.
FCFabric Element MIB Object Types
Description
Place port online.
Take port offline.
Initiate test procedures.
Description
Login may proceed.
Login cannot proceed.
Port is under test.
Failure after online/testing.
