connUnitPortStatus [connUnitPortTable]
Syntax
Table 2-17
Value
Integer
Access
Read-only
Status
Mandatory
Description
An overall protocol status for the port.
Note:
MIB Reference Manual Version 3.0
Declaration
1 (unknown)
2 (unused)
3 (ready)
4 (warning)
5 (failure)
6 (not participating)
7 (initializing)
8 (bypass)
9 (OLS)
For an E, F, or FL_port, the value is 3 (ok). For a U_port, the value is 2 (unused) if not faulty
with GBIC, 3 (warning) if not faulty but no GBIC, or 5 (failure) if faulty.
Fibre Alliance MIB Object Types
Description
Device cannot report this status.
FCAL Loop or FCPH Link reset protocol
initialization has completed.
Do not use.
Do not use.
Loop not participating and does not have a loop
address.
Protocol is proceeding.
Do not use.
FCP offline status.
