EF SERIES ECONOFRY
GAS FRYERS
MODEL
EF3
EF4
EF5
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
ML-52099
ML-114943
ML-114944
INSTALLATION &
OPERATION MANUAL
MODEL EF3
P.O. BOX 696, LOUISVILLE, KY 40201-0696
TEL. (502) 778-2791
FORM 35640 (02-05)
Advertisement
Table of Contents
Related Manuals for Vulcan-Hart EF SERIES
Summary of Contents for Vulcan-Hart EF SERIES
- Page 1 ML-52099 ML-114943 ML-114944 MODEL EF3 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART P.O. BOX 696, LOUISVILLE, KY 40201-0696 DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC TEL.
-
Page 2: Important For Your Safety
ALTERATION, SERVICE OR MAINTENANCE CAN CAUSE PROPERTY DAMAGE, INJURY OR DEATH. READ INSTALLATION, OPERATING MAINTENANCE INSTRUCTIONS THOROUGHLY BEFORE INSTALLING OR SERVICING THIS EQUIPMENT. IN THE EVENT OF A POWER FAILURE, DO NOT ATTEMPT TO OPERATE THIS DEVICE. — 2 — © VULCAN-HART, 2005... -
Page 3: Installation
PLEASE KEEP THIS MANUAL FOR FUTURE USE GENERAL Your Vulcan-Hart Gas Fryer is produced with quality workmanship and material. Proper installation, usage and maintenance will result in many years of satisfactory performance. It is suggested that you thoroughly read this entire manual and carefully follow all of the instructions provided. - Page 4 LOCATION CAUTION: The equipment area must be kept free and clear of combustible substances. Installation clearances: COMBUSTIBLE NONCOMBUSTIBLE CONSTRUCTION CONSTRUCTION Back: 6" (152 mm) 0" Right Side: 6" (152 mm) 0" Left Side: 6" (152 mm) 0" The installation location must allow adequate clearances for servicing and proper operation. A minimum front clearance of 35"...
-
Page 5: Gas Connections
ASSEMBLY Legs Position fryer in an open space near the final installation area. Tilt fryer back, being careful to avoid scratching the finish. Thread front legs clockwise into mounting plates provided on the bottom of the fryer until seated. Tilt to front and thread back legs similarly. Carefully raise fryer to its normal position and place it in the installing location. -
Page 6: Testing The Gas Supply System
TESTING THE GAS SUPPLY SYSTEM When test pressures exceed psig (3.45 kPa), the fryer and its individual shutoff valve must be disconnected from the gas supply piping system. When test pressures are psig (3.45 kPa) or less, the fryer must be isolated from the gas supply system by closing its individual manual shutoff valve. -
Page 7: Operation
If the shortening becomes overheated, a high temperature shutoff device will turn the gas valve off and extinguish the pilot. DO NOT relight the pilot until the shortening temperature is below 300°F (149°C). If this situation persists, contact your local Vulcan-Hart authorized service office. — 7 —... -
Page 8: Lighting The Pilot
LIGHTING THE PILOT 1. Turn thermostat OFF. Thermostat is located behind the door (Fig. 3). 2. Turn gas control valve knob to OFF/PILOT (Fig. 4). Wait 5 minutes for unburned gas to vent. 3. Push gas control knob in (Fig. 4). 4. -
Page 9: Frying Foods
FRYING FOODS • Heat shortening to set temperature. • Pieces of product to be fried should be about the same size to ensure the same doneness. • Drain or wipe dry raw or wet foods to minimize spatter when lowering into the hot oil. •... -
Page 10: Daily Filtering
DAILY FILTERING Turn gas valve OFF when draining or filling. The shortening should always be filtered while liquefied. A cold fryer will not drain properly because the shortening under the cold zone tube area will remain hard, even if the heat is on for a few minutes. - Page 11 CLEANING Daily Clean your fryer regularly. Keeping the fryer clean and free of accumulated grease will prevent stubborn stains from forming. Wash all exterior surfaces at least once daily. Use a cloth with warm water and a mild soap or detergent. Follow with a clear rinse, then dry. If regular cleaning is neglected, grease will be burned on and discolorations may form.
-
Page 12: Maintenance
Annually check the flue when it is cool to be sure it is free of obstructions. SERVICE AND PARTS INFORMATION To obtain service and parts information, contact the Vulcan-Hart Service Agency in your area (refer to our website, www.vulcanhart.com for a complete listing of Authorized Service and Parts depots.
