Utilizing the Command Line Interface
Virtual Interfaces:

Configuration Examples

The following examples display minimal interface configuration:
FastEthernet Example
interface fastethernet 1
no shutdown
T1 Example
controller t1 1/0
channel-group 3 timeslots 1, 3-6, 12
no shutdown
!
interface serial 1/0:3
encapsulation ppp
no shutdown
T1-PRI (ISDN) Example
controller t1 1/0/0
pri-group
controller t1 1/0/0:23
isdn switch-type primary-ni
isdn pool-member 1 priority 100
Dialer Example
interface dialer 4
ip address 11.1.2.2 255.0.0.0
dialer pool 5
interface serial 2/0
encapsulation ppp
dialer pool member 5
no shutdown
!
interface serial 2/1
encapsulation ppp
dialer pool member 5
no shutdown
2-18 Managing the XSR
Loopback - Range 0 to 15. Interface type: Internal Loopback.
Dialer - Range: 0 to 255, Interface type: Dialer.
VPN - Range: 0 to 255, Interface type: VPN tunnel/Dialer.
Multilink - Range: 1 to 32767, Interface type: VPN tunnel.
Frame Relay DLCI - Range: 16 to 1007, Interface type: Serial/FR.
Sub-interface: Each sub-interface correlates with a physical interface, ranging as follows:
ATM, BRI, and Serial - 1 to 30, Fast/GigabitEthernet - 1 to 64. The sub-interface number is
Port number.sub-interface number for single channel serial, port
number.channelgroupnumber.subinterface number for multi-channel.
+
Enables the interface
+
Begins configuring controller on NIM card 1, port 0
+
Enables the interface
+
Sets interface encapsulation type to PPP
+
Enables the interface
+
+
Enables ISDN, sets all timeslots to map to channel groups on NIM
+
Begins configuring dialer interface 4
+
Sets dialer 4 to use pool 5. Its members are physical ports
+
+
Sets interface encapsulation type to PPP
+
+
Enables the interface
+
+
Sets interface encapsulation type to PPP
+
+
Enables the interface
+
Begins configuring interface/port 1
+
Maps timeslots 1, 3, 4, 5, 6, and 12 to channel group 3
+
Configures channel group 3 defined above
Begins configuring PRI NIM card 1, port 0
+
Maps T1 NIM to D-channel sub-interface
+
Selects switch type
+
Adds a prioritized pool member to sub-interface
+
Sets IP address/subnet on dialer port
Configures serial interface on NIM card 2, port 0
Serial 2/0 is now a member of dialer pool 5 and will eventually be used by dialer 4
Configures serial interface on NIM card 2, port 1
Serial 2/1 is now a member of dialer pool 5 and will eventually be used by dialer 4
