Apm - Asus P8H61-M2 TPM SI User Manual

2.5.8

APM

Restore AC Power Loss [Power Off]
[Power On]
[Power Off]
[Last State]
Power On By PS/2 Keyboard [Disabled]
[Disabled]
[Space Bar]
[Ctrl-Esc]
[Power Key]
Power On By PS/2 Mouse [Disabled]
[Disabled]
[Enabled]
Power On By PCI [Disabled]
[Disabled]
[Enabled]
Power On By PCIE [Disabled]
[Disabled]
[Enabled]
Power On By Ring [Disabled]
[Disabled]
[Enabled]
Power On By RTC [Disabled]
[Disabled]
[Enabled]
2-20
The system goes into on state after an AC power loss.
The system goes into off state after an AC power loss.
The system goes into either off or on state, whatever the system state was
before the AC power loss.
Disables the Power On by a PS/2 keyboard.
Sets the Space Bar on the PS/2 keyboard to turn on the system.
Sets the Ctrl+Esc key on the PS/2 keyboard to turn on the system.
Sets Power key on the PS/2 keyboard to turn on the system. This feature
requires an ATX power supply that provides at least 1A on the +5VSB lead.
Disables the Power On by a PS/2 mouse.
Enables the Power On by a PS/2 mouse. This feature requires an ATX
power supply that provides at least 1A on the +5VSB lead.
Disables the PME to wake up from S5 by PCI devices.
Allows you to turn on the system through a PCI LAN or modem card. This
feature requires an ATX power supply that provides at least 1A on the
+5VSB lead.
Disables the PCIE devices to generate a wake event.
Enables the PCIE devices to generate a wake event.
Disables Ring to generate a wake event.
Enables Ring to generate a wake event.
Disables RTC to generate a wake event.
When set to [Enabled], the items RTC Alarm Date (Days) and Hour/
Minute/Second will become user-configurable with set values.
ASUS P8H61-M2 Series
