Serial-ATA Controller 1 [Enhanced]
This item appears only when you set the SATA Mode item to [IDE Mode].
[Disabled]
[Enhanced]
S.M.A.R.T. Status Check [Enabled]
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor system. When
read/write of your hard disk errors occur, this feature allows the hard disk to report warning
messages during the POST. Configuration options: [Enabled] [Disabled]
2.5.6
USB Configuration
The items in this menu allow you to change the USB-related features.
The USB Devices item shows the auto-detected values. If no USB device is detected, the
item shows None.
Legacy USB Support [Enabled]
[Enabled]
[Disabled]
[Auto]
EHCI Hand-off [Disabled]
[Enabled]
[Disabled]
2.5.7
Onboard Devices Configuration
HD Audio Controller [Enabled]
[Enabled]
[Disabled]
The following two items appear only when you set the HD Audio Controller item to
[Enabled].
Front Panel Type [HD]
Allows you to set the front panel audio connector (AAFP) mode to legacy AC'97 or high-
definition audio depending on the audio standard that the front panel audio module supports.
[HD]
[AC97]
Realtek LAN Controller [Enabled]
[Enabled] Enables the Realtek LAN controller.
[Disabled] Disables the controller.
2-18
Disables the SATA function.
Set to [Enhanced] to support more than four SATA devices.
Enables the support for USB devices on legacy operating systems (OS).
The USB devices can be used only for the BIOS setup program.
Allows the system to detect the presence of USB devices at startup. If
detected, the USB controller legacy mode is enabled. If no USB device is
detected, the legacy USB support is disabled.
Enables the support for operating systems without an EHCI hand-off
feature.
Disables the function.
Enables the High Definition Audio Controller.
Disables the controller.
Sets the front panel audio connector (AAFP) mode to high definition audio.
Sets the front panel audio connector (AAFP) mode to legacy AC'97
ASUS P8H61-M2 Series
