Non-Fader Phase (Non-F Phase) - Eclipse CD3200 Owner's Manual

Press the [ENTER] button to select
3
LPF or HPF.
Each time the button is pressed, the
setting item changes in the following
order.
*1
↔ HPF
LPF
*1: The cut-off frequency is 80Hz.
*2: The cut-off frequency is 100Hz.
Press the [SELECT] (Up/Down)
4
button to select Slope ON or OFF.
When it is ON, the slope is 12dB/oct.

Non-fader phase (Non-F Phase)

The merging of sound between the front and rear
speakers and the woofer can be improved by
selecting the phase. Switch the phase to a phase
which lets the speakers combine without any
disharmony.
Press the [SELECT] (Up/Down)
1
button to select Non-F Phase.
2
Press the [ENTER] button.
The mode will change to the non-fader
phase mode.
Press the [SELECT] (Up/Down)
3
button to select Normal or
Reverse.
Up:
Normal
Down:
Reverse
*2
How to operate the Sound Adjustment Mode
XII
71
