Hardware Specifications - HP Tc2110 - Server - 128 MB RAM Maintenance Manual

Chapter 9
Parameter
Operating Power

Hardware Specifications

Specification Characteristics
Processors This HP Server supports Intel Pentium 4 processors 1.6 GHz and above with 400 MHz FSB and
256KB L2 cache memory
Chipset Northbridge Brookdale (i845) or Southbridge ICH-2 chip set with 33 MHz PCI and 133 MHz
FSB speed support
Memory Supports up to three SDRAM DIMMS for a maximum total of 1.5 GB.
Supported DIMM type and sizes: 128MB, 256MB, or 512MB unbuffered, 168-pin, 3.3 volts, 72
bits wide, ECC single-bit correcting, multi-bit detecting.
Video Installed AGP video card supports up to 1920 x 1200 at 16.7M colors. For more information,
refer to "Video Display Modes" in this chapter.
SCSI SCSI model only; single channel Ultra-160 SCSI cable (3 connectors), Ultra 160 SCSI LED
cable
IDE Embedded Enhanced-IDE 33/66/100 dual-channel controller.
PCI Bus Three full-length 32-bit PCI slots at 33 MHz and 5 volts.
LAN Pro/100 VE Network connection.
I/O Two Serial ports; one bi-directional parallel port with ECP/EPP high-speed support; PS/2 style
mouse and keyboard connectors; two USB ports – supports USB printers, external modems, and
mouse and keyboard, but NOS dependant
CD-ROM Bundled CD-ROM drive; IDE interface; 48x speed or faster. Supports 16x40x max IDE DVD-
ROM drive
DVD-ROM Supports 60x40x max IDE DVD-ROM drive
106
Characteristics
250 W Continuous
Specifications
