RECEIVER LED INDICATORS

The LED indicators on the ST620RF Receiver are designed to give a clear and easily understood indication
of the current state of the system.
The various LED signal combinations and descriptions of what they indicate are shown in the table
below:
LED State
Blue On
Blue Flashing
once per
second
Blue Off
Green On
Green Flashing
for 4
seconds
Red On and
flashing
Yellow On
12
1/9/10
Indication
Receiver is in Manual mode and system is calling for heat.
Receiver is in Automatic mode and system is calling for heat.
Receiver is in Automatic mode and system is NOT calling for heat
Power is on
Receiver has received correct RF address and Command
signal when in Failsafe mode
Receiver is either receiving a new RF address code in SYNC mode,
or has failed to store the new RF address code when in SYNC mode
Receiver is in Failsafe mode after no RF signal received for over 1 hour
