Reverse lights
Rear side marker lights
4. Install the new bulb in the reverse order
of the removal procedure.
Form No.8BQ7-EA-10H
Black plate (365,1)
Owner Maintenance
High-mount brake light
1. Wrap the end of a flathead screwdriver
in a soft cloth and remove the trunk
handle by inserting the flathead
screwdriver in the position shown in
the figure and carefully prying the
handle off.
2. Disengage the pin in each clip securing
the trunk trim using a (
remove the screws and clips, and then
remove the trunk trim.
Removal
Installation
Maintenance and Care
) screwdriver,
8-33
