Pci/Pnp Setup - ECS G45T-M2 Manual

Resume by Ring (Disabled)
An input signal on the serial Ring Indicator (RI) line (in other words, an incoming
callon the modem) awakens the system from a soft off state.
Resume by PCI/PCI-E/Lan PME (Disabled)
These items specify whether the system will be awakened from power saving
modeswhen activity or input signal of the specified hardware peripheral or compo-
nent isdetected.
Resume by USB (S3) (Disabled)
This item allows users to enable or disable the USB device Walk-up from S3 mode.
Resume By PS2 KB (S3) (Disabled)
Use this item to allow keyboard activity to awaken the system from power saving
mode.
Resume By PS2 MS (S3) (Disabled)
This item enables or disables you to allow mouse activity to awaken the system from
power saving mode.
Resume on RTC Alarm (Disabled)
The system can be turned off with a software command. If you enable this item, the
system can automatically resume at a fixed time based on the system's RTC (realtime
clock). Use the items below this one to set the date and time of the wake-up alarm.
You must use an ATX power supply in order to use this feature.
Press <Esc> to return to the main menu setting page.
PCI / PnP Setup
This page sets up some parameters for devices installed on the PCI bus and those
utilizing the system plug and play capability.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Init Display First
Allocate IRQ to PCI VGA
: Move Enter : Select
F1: General Help
Init Display First (PCI)
Use this item to select which graphics controller to use as the primary boot devices.
Allocate IRQ to PCI VGA (Yes)
If this item is enabled, an IRQ will be assigned to the PCI VGA graphics system. You
set this value to No to free up an IRQ.vices.
Press <Esc> to return to the main menu setting page.
PCI / PnP Setup
Help Item
PCI
Yes
Select which graphics
controller to use as
the primary boot
device.
+/-/: Value F10: Save ESC: Exit
F9: Load Default Settings
Using BIOS
37
