Chapter 1 Migrating to a Cisco CRS-3 Carrier Routing System
Steps
To install a CRS-3 fabric card, see
Figure 1-14
1
2
1
2
Step 1 Attach the ESD-preventive wrist strap to your wrist and connect its leash to an ESD connection socket
on the front of the chassis or to a bare metal surface on the chassis.
Step 2 Choose an available CRS-3 fabric card slot for the CRS-3 fabric card.
Caution
OL-13669-03
Installing a CRS-3 Fabric Card
Captive screw
Ejector lever
To prevent ESD damage, handle the CRS-3 fabric card by its ejector levers, the CRS-3 fabric
card carrier edges, or the slide-assistance arm only. Do not touch any of the electrical
components, pins, and circuitry.
Cisco CRS-1 Carrier Routing System to Cisco CRS-3 Carrier Routing System Migration Guide
How to Migrate to a Cisco CRS-3 Carrier Routing System (4-Slot)
Figure 1-14 and follow these steps:
3
3
Direction of installation or removal
