Specifications; T Echnical S Pecifications - 3Com 3C17700 - SuperStack 3 Switch 4900 Getting Started Manual

C
Physical Dimensions
Environmental Requirements
Operating Temperature
Storage Temperature
Operating Humidity
Standards
Safety
Agency Certifications
EMC
Emissions
Immunity
Power Consumption
T
ECHNICAL
The technical specifications for the Switches in the Switch 4900 Family
are the same unless otherwise stated.
Switch 4900: Switch Height: 65.8 mm (2.59 in.) x Width: 440 mm (17.3 in.) x
Depth: 363.4 mm (14.30 in.) (not including bulge). Weight: 6.3 Kg (13.88 lbs)
Switch 4900 SX: Height: 65.8 mm (2.59 in.) x Width: 440 mm (17.3 in.) x
Depth: 363.4 mm (14.30 in.) (not including bulge). Weight: 6.0 Kg (13.22 lbs)
Switch 4924: Height: 65.8 mm (2.59 in.) x Width: 440 mm (17.3 in.) x Depth:
413 mm (16.27 in.) (not including bulge). Weight: 6.4 Kg (14.10 lbs)
Switch 4950: Height: 65.8 mm (2.59 in.) x Width: 440 mm (17.3 in.) x Depth:
413 mm (16.27 in.) (not including bulge). Weight: 6.91 Kg (15.23 lbs)
0 ° to 40 °C (32 ° to 104 °F)
–10 ° to +70 °C (14 ° to 158 °F)
10–95% relative humidity, non-condensing
EN60068 to 3Com schedule (Package testing: paras 2.1, 2.2, 2.30, and 2.32.
Operational testing: paras 2.1, 2.2, 2.30 and 2.13).
UL 1950 / UL60950, EN60950, CSA 22.2 No. 950 / CSA 22.2 No. 60950,
IEC 60950, IEC 825-1 (4900 SX and 4950 only), EN 60825-1 (4900 SX and 4950
only)
CISPRR 22 Class A, EN55022 Class A, FCC Part 15 Subpart B Class A,
ICES-003 Class A, VCCI Class A, AS/NZS 3548 Class A, EN61000-3-2
EN 55024
Switch 4900: 308
watts maximum
Switch 4900 SX:
162 watts maximum
Switch 4924: 254 watts maximum
Switch 4950: 200 watts maximum
S
PECIFICATIONS
