Power Supply

WARNING!
active AC outlet. To avoid possible personal injury and damage to the equipment the power cord should
be disconnected from the computer and/or the AC outlet before opening the computer.
1. Prepare the computer for disassembly
2. Remove the computer cover
3. Rotate the drive cage up and disconnect the power cables from all of the drives.
4. Press the release latch (1) and rotate the power supply to its full upright position (2).
5. Disconnect the power cables from the system board and lift the power supply straight up and out
of the chassis (3).
Figure 7-58
To install the power supply, reverse the removal procedure.
CAUTION:
are not cut by the drive cage and are not pinched by the rotating power supply.
ENWW
Voltage is always present on the system board when the computer is plugged into an
(Computer Cover on page
Removing the Power Supply
When installing the power supply cables, make sure they are properly positioned so they
(Preparation for Disassembly on page
64).
61).
